seperation application palm oil vibrating separator Full Technical support and Spares Service to keep your Lines Running. | ||
| Model: NVS1500-AS | |
General Technical Data: | ||
Diameter | 1500mm | |
Layer | 1-4 decks | |
Opening | Up to 635mesh(18 microns) | |
Mesh material | Stainless steel 304,316L,Carbon Steel | |
Voltage | 3 phase,380V,50HZ 3 phase,415V,50HZ.(Customized) | |
Power | 1.5KW | |
Effective sieving area | 1.5036M2 | |
Features 1.CE&ISO Certificate 2.Sieve from 5mm-15 Micro 3.Customized vibrating screen 4.Warranty:13 months 5.Reply in 24 hours | How to select a suitable vibrating screen? | |
1.what’s the material and its density? | ||
2.what’s the mesh size? And which size of powder do you need? | ||
3.What’s the percentage of every size in your material? | ||
4.What’s your excepted capacity? | ||
Hope you for inquiry us and an accurate quotation will be given.Thank you! | ||
Guarantee And After-sale Service: | ||
1. 13 months guarantee for whole machine. | ||
2. 24 hours technical support by email or telephone. | ||
3. Calling or door-to-door service. | ||
Packaging & Shipping: | ||
1.With plastic film wrapping machine | ||
2.put the machine into the standard wooden case | ||
3.In the cases with two stick fixed the machine | ||
1. What it does?
a:Separate solids from liquids or segregate dry materials into various sizes.
2. How it works?
Vibration is accomplished by eccentric weights on the upper and lower ends of the motion-generator shaft. and The angle of lead given the lower weight with relation to the upper weight provides variable control of the spiral screening pattern.
3. Any self-cleaning devices on the sieving machine?
Yeah, Bouncing ball or Ultrasonic system could be installed.
4. How many kinds of material are supported?
A. All stainless steel (201, 304, 316L)
B. All carbon steel Q235A
C. Contact part Stainless steel.
5. About the phase and the voltage?
0.12-0.55 kw single phase and three phase are both supported.
0.55-2.2 kw Three phase is just supported.
110V, 220V, 380V, 415V, 450V, 480V are supported. (50HZ OR 60 HZ).
6. How long is the warranty?
The warranty is 12 month(except the wearing parts includes sealing strip, bounce ball and sieve mesh, etc.). Because different usage, the wearing parts will have different life.
7. OEM order and labeling services are supported?
Yeah, OEM order and labeling services are supported. And we seek global partners.
8. Whether the site visits is supported or not?
Yeah, site visits will be highly welcome. Airport picking up and hotel booking are both supported. half hour to both HongQiao international Airport and Pudong Airport.
