Friction Hinge,Friction Stay Hinge,Window Friction Stay
Style |
Size/inch |
Material |
Application |
Max. Window |
Opening angle |
Groove width |
Thickness |
Stack Height |
||
Weight |
Height |
Width |
||||||||
4bars |
10"--18" |
SS202 |
It is suitable for large-scale or heavy-duty casement window and top hung window. |
22kg --- 44kg |
1200mm --- 1500mm |
600mm --- 800mm |
50°±3° 85°±3° |
22mm |
2.5mm 3.0mm |
16.5mm 17mm |
Advantage
* Connecting with the rivet of bottom slot steady, Exponentially increase the friction hinge bearing capacity, and enhanced security.
* The design slider, will reduce the resistance of the slider.
* Window fully opened, in the form of open space, visual effects, and easy for emergency escape.
Product Picture
Test Report
Package
| Lengh | 10'' |
| Slot width | 22mm |
| Weight | 264g/pc |
| Ctn quantity | 100pcs |
| N.W. | 26.4kgs/ctn |
| G.W. | 26.7kgs/ctn |
| Volume | 33*20*17(cm) |
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------
There are other friction hinges for your choice.
(Please click the product pictures and check the detail.)
