Help CenterISO, CE, EAC Certified Large Output/capacity Sylvine NPFS Gyratory Screener
Related Products
-
ISO, CE, EAC Certified Large Output/capacity Organic Fertilizer NPFS Gyratory ScreenerUS$ 9,000 - 50,000MOQ: 1 Set -
ISO, CE, EAC Certified Large Output/capacity Long-acting Fertilizer NPFS Gyratory ScreenerUS$ 9,000 - 50,000MOQ: 1 Set
-
ISO, CE, EAC Certified Large Output/capacity Quick Acting Fertilizer NPFS Gyratory ScreenerUS$ 9,000 - 50,000MOQ: 1 Set
-
ISO, CE, EAC Certified Large Output/capacity Potassium Salt NPFS Gyratory ScreenerUS$ 9,000 - 50,000MOQ: 1 Set
-
High Frequency Mining Application Screener PlantUS$ 1 - 2MOQ: 1 Set
Full Technical support and Spares Service to keep your Lines Running
Safeguarding the quality and your reputation!!
Model sizes |
500x1000,500x1500,1000x2100,1000x3000,1500x3000,1800x3600,2000x5000 |
Layer |
1~3 decks |
Mesh |
Within 100 mesh |
Mesh material: |
Stainless steel 304,316L,201,Nylon |
Using Range: |
Agriculture |
Voltage: |
3 phase, 380V, 50HZ or |
Power: |
0-300W Adjustable |
Screening ratio |
≥95% |
Warranty: |
13 months |
Particle feed size: |
150micron up to 20 mm |
Feed rates: |
Up to 65T/h |
Anti blinding systems: |
- Rubber balls |
Motor power |
1.5kw,2.2kw,4kw,5.5kw,7.5kw,11kw |
Layer |
Model |
Dimension mm |
Travel distance mm |
Motor |
A mm |
B mm |
C mm |
D mm |
Weight/Kg |
|
KW |
RPM |
|||||||||
1 |
NPFS 500X1500 NPFS 1000X2100 NPFS 1000X3000 NPFS 1500X3000 NPFS 1800X3600 NPFS 2000X5000 |
100x1500 1000x2100 1000x3000 1500x3000 1800x3600 2000x5000 |
52 64 64 64 76 92 |
1.5 2.2 4 5.5 7.5 11 |
940 960 960 960 960 960 |
2235 3280 4485 4236 5305 6770 |
700 960 1050 1360 1500 1980 |
730 1156 1156 1778 2180 2245 |
810 1200 1200 1892 2430 2230 |
350 960 1100 2300 3600 5000 |
2 |
NPFS 500X1500 NPFS 1000X2100 NPFS 1000X3000 NPFS 1500X3000 NPFS 1800X3600 NPFS 2000X5000 |
100x1500 1000x2100 1000x3000 1500x3000 1800x3600 2000x5000 |
52 64 64 64 76 92 |
1.5 2.2 4 5.5 7.5 11 |
940 960 960 960 960 960 |
2235 3280 4485 4236 5305 6770 |
700 960 1050 1360 1500 1980 |
730 1156 1156 1778 2180 2245 |
810 1200 1200 1892 2430 2230 |
400 1080 1230 2600 3900 5200 |
3 |
NPFS 500X1500 NPFS 1000X2100 NPFS 1000X3000 NPFS 1500X3000 NPFS 1800X3600 NPFS 2000X5000 |
100x1500 1000x2100 1000x3000 1500x3000 1800x3600 2000x5000 |
52 64 64 64 76 92 |
1.5 2.2 4 5.5 7.5 11 |
940 960 960 960 960 960 |
2235 3280 4485 4236 5305 6770 |
760 1050 1080 1460 1560 2040 |
730 1156 1156 1778 2180 2245 |
810 1200 1200 1892 2430 2230 |
450 1250 1500 3200 4100 5500 |
Sylvine NPFS gyratory screener Feature:
l handle both large capacity and fine mterial
l Low angle, Gyratory-Reciprocating Motion gently sifts the material
l Multi deck screeners produce several grades of product in one machine
l Totally enclosed with effective sealing for clean operation
l Durable constructon and wear-resistant impact areas for long life and continuous operation
Anti-blockage bouncing balls in place for increase of throughput
EX approved IP65 motor &Stable Driving head lubracating for lifetime.
Plastic wrapping around for initial packing
Strong fumigated wooden case as master shiper
After-sale Service:
- 13 months guarantee for whole machine
- 24 hours technical online support
- onsite service
Case onsite
NPFS 1530/NPFS1030 Model separation equipment processing fertilizer.
