inverter ac dc aluminium tig welding machine

Specifications

TIG Welding Machine
1.Save engery
2.dc argon arc welding machine
3.MOS/IGBT inverter technology

 TIG-200P Welding Machine



Technical Specification

Specification	AC/DC TIG-160P		AC/DC TIG-200P
Input Voltage	AC/DC220V±15%, 50/60Hz		AC/DC220V±15%, 50/60Hz
No-load Voltage(V)	62		62
Output Current Range(A)	5-160		5-200
Rated Duty Cycle(%)	60		60
Insulation Class	B		B
Up-slope Time(S)	0-1		0-1
Down-slope Time(S)	0-10		0-10
Base Current(A)	0-160		0-200
Arc Force(A)	0-50		0-50
Pulse Frequency(Hz)	0-200		0-200
Pulse Duty(%)	10-90		10-90
Clean Width(%)	20-80		20-80
Post Gas(S)	0-10		0-10
Weight(KG)	26		26
Dimension(MM)	580*370*510		580*370*510
	MMA	TIG	MMA	TIG
Rated Input Capacity(KVA)	5.3	3.3	7	4.5
Rated Output Voltage(V)	26.4	16.4	28	18
Arc-starting	Torch	HF	Torch	HF













Main Features of AC/DC TIG-200P

1. High quality square wave current, speed current transform, stable arc, no need to use HF in stabling the arc.

2.Concentrated heat, solid arc, easy to fill in the wire, especially suitable for the wire filling welding in bicycle industry.

3.Strong capability for clearing oxidation film, the clear width can be adjusted continuously and the welding seam is beautiful and bright.

4.Can meet the demand of butt welding, angle welding, etc.

5.Widely used in aluminum, carbon steel, stainless steel, cooper and titanium welding, etc.

6.With complete accessories.

7.Carton box.
