Specifications
rubber magnetic sheet1.Material:magnet
2.Customized logo,size and design.
3.Eco-friendly
magnetic film rubber magnetic sheet with Adhesive
Size Range (unit: mm) |
Min |
Max |
|
Roll |
length |
/ |
/ |
width |
/ |
610 |
|
thickness |
0.4 |
1.5 |
|
Sheet |
length |
/ |
1000 |
width |
/ |
630 |
|
thickness |
0.3 |
10 |
|
Strip |
width |
5 |
80 |
thickness |
0.9 |
10 |
|
Remark |
the common packing for roll material is 30m/roll or 50m/roll; it also depends on the specific width and thickness of the product as well as the shipping terms. |
||
2. Tolerance OF FLEXIBLE FERRITE MAGNET
Tolerance (unit: mm) |
Calendered Sheet |
Extruded Strip |
Die Cut Part |
|
length |
-3 |
+1.5/-0(m) |
+/-0.3 |
|
width |
-3 |
+/-0.3 |
+/-0.3 |
|
thickness |
>=1.0 |
+/-0.08 |
+/-0.15 |
+/-0.08 |
<1.0 |
+/-0.05 |
+/-0.05 |
||
3.PHYSICAL PROPERTIES OF FLEXIBLE FERRITE MAGNET
TYPE |
MH-7 |
MH-9 |
MH-12 |
MH-13 |
tensile strength (mPa) |
>2.0 |
>2.3 |
>3.0 |
>2.8 |
elongation (%) |
20 |
30 |
30 |
18 |
hardness (shore D) |
30-40 |
30-45 |
30-50 |
30-45 |
density (g/cm3) |
3.65-3.75 |
3.65-3.75 |
3.70-3.80 |
3.70-3.80 |
temperature range (°C) |
-40~100 |
-40~100 |
-40~90 |
-40~90 |
1. We are professional manufacturer and have 2 factories over 12 years.
2. Rich experience in the magnetic industry and magnetic products.
3. Our senior sales staff take “customer first, continuous improvement” as their working principle. Quickly response and efficiency working style get high praise from our customers.
4. High-quality product with reasonable price and fast delivery time. All the magnetic material and magnetic products pass the testing such as RoHS,EN71,ASTM,REACH.
Q1: What's your warranty policy?
A1: For all the products, we have one-year warranty. All of our goods are 100% tested working before sent to you. In case there are unexpected damages during delivery, please do check before you sign for the package.
Q2: What's your minimum order quantity?
A2: Our MOQ is not the same based on different items. Small orders are also welcome, but the unit price is also difference from wholesale price.
Q3: What package do you use for the products?
A3: Usually we have professional retail package for the products. Customized package are also available based on certain MOQ.
Q4: How about the payment term?
A4:.Usually we adopt T/T term. 30% T/T in advance as deposit,70% balance payment before shipment. If you have other inquiries, please contact us to talk more.
Q5: I am very satisfied after I read your FAQ, how can I start to purchase my order?
A5: Please click the "contact supplier" at the right side of this page or contact our sales on Trade Manage online!
