Made in China- CYET-120N(8.5HP) KUBODA TYPE Single-cylinder Diesel Engine

Name: Made in China- CYET-120N(8.5HP) KUBODA TYPE Single-cylinder Diesel Engine
Brand: CHANGYING
SKU: 110464009
Availability: InStock

US$ 480 - 495 MOQ: 1 Set

Key Specifications

Condition:

New

Usage:

Automobile

Fuel:

Diesel

Changzhou Feng Qing Mechanical And Electrical Equiment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Usage Automobile

Fuel Diesel

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Water-cooled

Start Kick Start

Place of Origin Jiangsu, China

Brand Name CHANGYING

Model Number CYET120N

Dimension(L*W*H) 795*370*560

Weight 104

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Made in china- CYET-95N(8.5HP) KUBODA TYPE Single-cylinder Diesel engine
Powerful GDI energy


CYET95-140DI kubota type diesle engine

Model	ET95DI	ET110DI	ET120DI	ET125DI	ET140DI
Type	Single cylinder Horizontal Water-cooling
combustion Type	Direct
cylinder bore(mm)	88	92	94	94	97
Piston stroke	90				96
12H rated output (kw(ps)/t/min)	6.25(8.5)/2400	7(9.5)/2400	8.02(10.9)/2400	8.1(11)/2400	9.2(12.5)/2400
1H rated output (kw(ps)/t/min)	6.99(9.5)/2400	8.09(11)/2400	8.82(12)/2400	9.2(12.5)/2400	10.3(14.0)/2400
Piston displacement (L)	0.547	0.598	0.625	0.666	0.709
combustion ratio	18
Piston average speed (m/s)	7.2	7.2		7.2	7.68
Specfic fuel consumpion (g(kw-h)	<=248
Lube consumption (g(kw-h)	<=2.72
Fuel injection pressure	21+-0.49(Direct)
Valve clearance (cold)(mm)	"Intake valve:0.20-0.30 Exhaust valve:0.25-0.35"
Advance angle of fuel delivery	18+-1
Valve timing	Intake valve open (TDC):15 Intake valve close (BDC):35
Valve timing	Exhaust valve open (BDC):15 Exhaust valve close (TDC):35
Model of fuel pump	BFGIKD 75Z01
Model of needle	ZCK145S428(Direct)				DLLA140PN013
Lubrication method	Combined with oil mist splashing
starting method	Hand cranking
lllumination	Fan dynamotor 12V/45W
Direction of rotation of the flywheel	Counter-clockwise(observer facing the flywheel end )
Speed governor method	Macthine whole centrifugal
N.W./G.W.(KG)	<=104/113	<=103/117	<=110/119
Engine size (mm(LWH))	795370560
Packing size (mm(LWH))	830370640
LOAD QTY	20"FT:120PCS 40"FT:210PCS
