building material concrete wire meshreinforcement wire mesh
cement wire mesh
wire 5-16mm
mesh 10*10cm,15*15cm,20*20cm
concrete wire mesh for building(factory)
1. Technical Info:
Wire diameter: for welded steel bar panel ranges from 5mm to 16mm.
Welded bar panel opening: 75mm to 300mm.
Panel length: 100cm to 1200cm.
Panel width: 100cm to 230cm
2.Applications:
used in construction reinforcement, the ground for the tunnels, bridges, highway, airport and wharf, also in construction of wall body, making of floors, ceilings, wall body, concrete road, bridge surface, airport, tunnel lining, concrete piping, mesh rack, international partritioning, shelving etc.
3.STANDARD SPECIFICATION
STANDARD MESH FABRIC FOR CONCRETE REINFORCEMENT |
No. | Types | Wire Spacing | Wire Diameter | Sheet | Weight per | ||
Main mm | Cross mm | Main mm | Cross mm | ||||
1 | A98 | 200 | 200 | 5 | 5 | 2.15 X 5.00 | 16.7 |
2 | A142 | 200 | 200 | 6 | 6 | 24.1 | |
3 | A193 | 200 | 200 | 7 | 7 | 32.8 | |
4 | A252 | 200 | 200 | 8 | 8 | 43.0 | |
5 | A393 | 200 | 200 | 10 | 10 | 67.1 | |
6 | B503 | 100 | 200 | 8 | 8 | 64.7 | |
7 | B785 | 100 | 200 | 10 | 8 | 89.1 | |
8 | A98* | 200 | 200 | 5 | 5 | 1.80 X 3.00 | 8.3 |
9 | A142* | 200 | 200 | 6 | 6 | 12.0 | |
10 | A252* | 200 | 200 | 8 | 8 | 1.75 X 3.00 | 21.0 |
11 | A393* | 200 | 200 | 10 | 10 | 32.9 | |
12 | Q92 | 150 | 150 | 4.2 | 4.2 | 2.15 X 5.00 | 15.9 |
13 | Q131 | 150 | 150 | 5 | 5 | 22.5 | |
14 | Q188 | 150 | 150 | 6 | 6 | 32.4 | |
15 | Q257 | 150 | 150 | 7/5(? | 7 | 39.7 | |
16 | R92 | 150 | 250 | 4.2 | 4.2 | 12.8 | |
STEEL | Cold reduced, high tensile, deformed, according to BS 4482 | ||||||
Welded steel mesh reinforcement
rebar welded wire mesh panel
concrete reinforcing wire mesh for building
cement concrete mesh panel
