Qingdao Antai Hook Type Shot Blasting Machine
US$ 40,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Antai
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polishing Machine/lifting Hook Shot Blasting Machine/derusting MachineUS$ 20,000 - 50,000MOQ: 1 Set -
Q37 Series Double Hook Type Shot Blasting MachineUS$ 60,000 - 80,000MOQ: 1 Set
-
Q3720-20 Hook Shot Blasting Machine/shot Blasting MachineUS$ 5,000 - 20,000MOQ: 1 Set
-
Blast Shot/hook Shot Blasting Machine/shot Blasting MachineUS$ 5,000 - 20,000MOQ: 1 Set
-
Hook Type Shot Blasting Machine/shot Blasting MachineUS$ 5,000 - 20,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
Antai
Model Number
Q3730
Feature
Critical Cleaning / Residue Free, Rust / Corrosion Inhibitor
Fuel
Electric
Certification
CE, Other, CE, ISO BV
Use
Burnishing, Descaling / Stripping
Cleaning Process
Other, Steel shot
Cleaning Type
Other, shot blasting
Industry Used
Other, casting,steel structure,steel industry
Material
Metal / Coil
Power(W)
64.4KW
Dimension(L*W*H)
7085*4650*8652
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Double hook or single hook2.Two turbine wheels
3.Competitive price
4.ISO 9001:2008
5.Rotary blasting process
Hook shot blasting machine is widely used in foundry plant, forging tal processing.
The double hook or Y track rail shot-blasting machines are the most versatile in terms of typical employment and size of the materials to be treated. Moreover the motorised hoists installed on the overhead conveyor allow the lifting of very high loads. The customer can choose the size and loading capacity of the machine according to the parts to be shot-blasted.
Technical specification:
| Type | Size of workpiece cleaned | Carrying weight of single hook | Capacity of shot-blasting | Lifting capacity of hoist | Separating capacity of separator | Ventilation capacity | Power(excluding dedusting) | Outline dimensions |
| mm | kg | kg/min | t/h | t/h | m3/h | kw | mm | |
| Q376 | Ø600*1100 | 500 | 2*120 | 15 | 15 | 5000 | 19 | 4429*2850*3443 |
| Q378 | Ø800*1500 | 1000 | 2*200 | 22 | 22 | 8000 | 32.5 | 4325*2660*5009 |
| Q3710 | Ø900*1600 | 1000 | 2*250 | 30 | 30 | 9000 | 36.55 | 5047*3850*5156 |
| QD3710 | Ø900*1600 | 1000 | 2*250 | 30 | 30 | 9000 | 39.95 | 5844*2742*5716 |
| Q3720 | Ø1400*2300 | 2000 | 3*250 | 45 | 45 | 15000 | 61.27 | 6110*3599*7842 |
| Q3730 | Ø1600*2300 | 3000 | 3*250 | 45 | 45 | 15000 | 64.4 | 7085*4650*8652 |
| Q3750 | Ø1800*2500 | 5000 | 4*250 | 60 | 60 | 18000 | 78.4 | 7062*5460*8652 |
| Q3780 | Ø2000*3000 | 8000 | 4*250 | 60 | 60 | 20000 | 81.5 | 8050*6400*8526 |
Photos of double hook shot blasting machine:
