High Quality Zirconia Sensor Tube With Electrode Tube
US$ 1 - 10
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Type:
Ceramic Tubes
Application:
Industrial Ceramic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Pressure Zirconia Ceramic Tube BushingUS$ 1 - 10MOQ: 1 Piece -
Advanced Ceramic Alumina and Zirconia Insulation Tube Sleeve Quality ChoiceUS$ 1 - 10MOQ: 1 Piece
-
Zirconia Temperature Measurement Tube Refined MonocrystallineUS$ 1 - 10MOQ: 1 Piece
-
Zirconium Oxide Thermocouple Protection TubeUS$ 1 - 10MOQ: 1 Piece
-
High Purified and Tip Quantity Zirconia Ceramic TubeUS$ 1 - 10MOQ: 1 Piece
Place of Origin
Shanghai, China
Type
Ceramic Tubes
Application
Industrial Ceramic
Material
Zirconia Ceramic
Model Number
KS12356
Brand Name
kessen
Specifications
1 Material:Zirconia Color:white2 Extreme hardness and form stability
3 High compressive strength
4 Corrosion resistance
Zirconia ceramics performance |
Density |
g/cm3 |
≥6.0 |
Water absorption |
% |
<0.05 |
|
Firing temperature |
°C |
1550 |
|
Hardness |
HV |
1350 |
|
Bending strength |
MPa |
950 |
|
Compression strength |
Mpa |
25000 |
|
Breaking tenacity |
Mpa·m1/2 |
8 |
|
Hot expansion coefficient |
/°C |
9.5x10-6 |
|
Processing technology | |||
Process range (mm) | |||
Outside Diameter |
1---300 |
||
Inside Diameter |
0.5---300 |
||
Length |
0.5---600 |
||
Accuracy of working (mm) | |||
Perpendicularity |
0.001 |
||
Concentricity |
0.001 |
||
Roundness |
0.0005 |
||
Straightness |
0.005 |
||
Parallelism |
0.01 |
||
Planeness |
0.005 |
||
Roughness |
0.005 |
||
Fit clearance |
0.005 |
||
