High purity MgO crucibles for melting
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Type | Ceramic Parts | |
| Application | Refractory | Model Number | KS-MG100 | |
| Brand Name | kessen |
Product Description
Magnesia crucible
Advantages:
1. Energy saving: 10-20%
2. Short warm-up time, free ovens, free sintering, use can be sent directly to electricity smelting.
3. High refractoriness, one turn induction coil pressed at bottom and the furnace volume is larger
than the traditional hand-made ones, high effective power, significantly improved the rate of melting furnace.
4. Quick and easy installation and removal
5.Furnace installation assembly, greatly improved labor productivity, effectively reducing the labor
intensity.
6. Improve the quality of liquid steel. The product has high refractoriness, good thermal stability,
resistance to high temperature erosion of liquid steel, greatly reduces the liquid steel slag.
7. Long service life: This product uses the optimal level of granularity and with high performance
composite materials, using pressure forming, so furnace life and stability is greatly improved.
8. Safe to use: the outside furnace layer (safety lining) may offer safety when failures happen,
effectively eliminating the accidents of wear ovens.
Magnesia crucible technical parameters:
| Purity | 98% (Al2o3:2%) |
| Compressive strength | 1000Mpa |
| Bending strength | 300 Mpa |
| Moh’s hardness | 5-6 |
| Max temperature | 2000°C |
| Density | 3.2g/cm3 |
| Service life | At1700 °C,you can use it for more than 200 furnaces |
High magnesia crucible technical parameters
| Purity | 99.9% |
| Compressive strength | 1800Mpa |
| Bending strength | 600 Mpa |
| Moh’s hardness | 5-6 |
| Max temperature | 2200°C |
| Density | 3.5g/cm3 |
| Type | OD(mm) | ID(mm) | Outer height(mm) |
| KS-M0.3 | 42 | 30 | 60 |
| KS-M0.5 | 55 | 35 | 135 |
| KS-M0.7 | 70 | 50 | 100 |
| KS-M01 | 70 | 50 | 140 |
| KS-M02 | 85 | 70 | 165 |
| KS-M04 | 118 | 90 | 180 |
| KS-M08 | 130 | 106 | 200 |
| KS-M09 | 130 | 106 | 225 |
| KS-M12 | 140 | 116 | 245 |
| KS-M18 | 150 | 120 | 300 |
| KS-M20 | 160 | 130 | 280 |
| KS-M22 | 170 | 140 | 280 |
Package
Carton,Plywood
Shipping
We can supply you the translation methods whatever you want.
--By express (DHL/Fedex/etc.)
--By Air to your nearest Airport
--By Sea to your nearest Seaport
--By the sellers’ shipping agent
Our products are warranted to be free from defects in materials or workmanship for 6months from the date of purchase. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.
1.Your inquiry related to our products or prices will be replied within 24hours
2. Guarantee samples quality same as mass production quality
3. Offering the support to solve the problem in the application or selling period.
4. Competitive prices based on same quality.
Shanghai Kessen Ceramics Co., Ltd. is a wholly owned subsidiary of Shanghai Kessen
Group Corp. Professional design, production and sale of precision ceramics, refractory
ceramics, and new inorganic non-metallic materials, that is alumina, zirconia, magnesia,
silicon nitride and silicon carbide as main raw materials. After a series of synthetic and
refining processing to make superfine powder. By means of 1700c ultra-high temperature and
high pressure process sintering, the products have high temperature resistance, corrosion,
wear, pressure insulation and other outstanding features. They are widely used in electronics,
metallurgy, petrochemical, information, mechanical, electrical, autos, aerospace, new energy,
military, defense and other industries.
Shanghai Kessen Group Corp
Shanghai Kessen Ceramics Co Ltd
No1115 Road Yongxin Jiading Shanghai 201800 China
Tel:86-21-51099195 Fax:86-21-51010816 Skype:kessen.alan
1. Can you accept OEM?
Yes!.We can manufacture as per your request specification.
2. Can you deliver the goods via our shipping agent?
Yes, we could help you make the delivery using your shipping agent
3. Can you supply sample?
Yes.We would like to give you suitable suggestion according to your detail application.
4. What about your After-sales service?
Yes.We promise that we can change or refund products if there are any quality problem.
If you need more professional help, please contact us. Our technical engineers would like to give advices according to your requirements
