Magnesium Oxide Ceramic Crucible

Magnesium Oxide Ceramic Crucible thumbnail-1
Magnesium Oxide Ceramic Crucible photo-1
US$ 1 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Type:
Ceramic Plates
Application:
Industrial Ceramic
Contact Supplier Request Quote Chat Now
Shanghai Kessen Ceramics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Type Ceramic Plates
Application Industrial Ceramic
Material Alumina Ceramic
Model Number KS-W-62
Brand Name kessen

Specifications

Magnesium oxide ceramic crucible
-Heat resistant
-Wear resistance
-Good insulation

    Magnesium oxide ceramic crucible

99.5% alumina ceramic plates
-Heat resistant
-Wear resistance
-Good insulation
-High strength

99.5% alumina ceramic plates

Features:

1) A variety of specifications available.

2) Satisfy various technical request

3) Lower medium spoilage

4) Good insulation performance and high temperature resistance

5) High strength

6) Wear resistant performance


We can supply the products according to customer's drawings, samples and performance requirement.



Performance For Industrial Ceramic
Item
                                                  		  Unit                    95 Al2O3              96 Al2O3              99 Al2O3
Physical Characteristics               Heat resistance 0C 1500 1550 1800
Bulk density                     g/cm3 3.6 3.6 3.9
Water absorption                % 0 0 0

Mechanical Characteristics     		Flexural strength                Mpa 320 340 360
Hardness vickers              Gpa 12.2 13.5 15.6
Elastic modulus                  Gpa 280 320 370
Poisson’s ratio                        0.22 0.23 0.23
Thermal Characteristics            Linear expansion coefficient                          (20-5000C) 10-6/0C 7.1 7.2 8
Thermal conductivity              w/(m.k) 16 24 32
Specific Heat                         *10-3J/(kg*K) 0.78 0.78 0.9
Electrical Characteristics          Dielectric constant (1MHZ) - 9 9.4 9.9
Dielectric loss angle            *10-4 15 5 1
Dielectric strength             *106V/m 12 15 15
Processing technology
Process range (mm)
Outside Diameter 1---300
Inside Diameter 0.5---300
Length 0.5---600
Accuracy of working (mm)
Perpendicularity 0.001
Concentricity 0.001
Roundness 0.0005
Straightness  0.005
Parallelism 0.01
Planeness 0.005
Roughness  0.005
Fit clearance 0.005

Magnesium oxide ceramic crucibleMagnesium oxide ceramic crucibleMagnesium oxide ceramic crucible
