Diameter 8mm High Alumina Ceramic Tubes With Holes
US$ 1 - 10
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Type:
Ceramic Rods
Application:
Refractory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Diameter 12mm Thread Alumina Ceramic TubeUS$ 1 - 10MOQ: 1 Piece -
Diameter 20mm Thread Alumina Ceramic TubeUS$ 1 - 10MOQ: 1 Piece
-
Diameter 9mm Alumina Thermocouple TubeUS$ 1 - 10MOQ: 1 Piece
-
Diameter 5mm High Alumina Ceramic Tubes With HolesUS$ 1 - 10MOQ: 1 Piece
-
Diameter 10mm 99% Alumina Ceramic TubeUS$ 1 - 10MOQ: 1 Piece
Place of Origin
Shanghai, China
Type
Ceramic Rods
Application
Refractory
Material
Alumina Ceramic
Model Number
ks002
Brand Name
kessen
Specifications
Diameter 8mm high alumina ceramic tubes with holes1.High temperature
2.Good insulation
3.High strength
4.Precision Process
Productive Technology:
Alumina ceramic is the special corundum ceramic that been sintered under 1800 °C with the
main raw material of Al2O3 and flux of rare metal oxide.Using the high strength organic/inorganic
bond to felt together, and then grinding to the size as drawing required.
Advantages:
1.High temperature
2.Good insulation
3.High strength
4.Precision Process
Alumina Ceramics Properties | |||
| Alumina Content | Unit | 95% | 99% |
Density | g/cm3 | 3.6 | 3.8 |
Water absorption | % | <0.4 | <0.2 |
Firing temperature | °C | 1600 | 1800 |
Hardness | HRA | 70 | 80 |
Coefficient of linear expansion | *10-6/°C | 5.5 | 5.3 |
Dielectric constant | 9 | 10.5 | |
Volume resistivity | Ω·cm | — | 1013 |
Breakdown voltage | KV/mm | 14 | 15 |
Breaking strength | Mpa | 250 | 300 |
