Specifications
HD-l-01 good quality automatic labelling machine:1. Automatic good quality Labeling machines
2. PLC control with magic eyes
HD-l-01 good quality automatic labelling machine :
We are not only Labeler manufacturer in providing different function Labeling Machine with good experience for many years, but also the professional solution provider to give the most suitable labeling proposal according to client’s product shape or size either regular or irregular, either use adhesive paper label or plastic sticker label. Our machine is mainly made of good quality SUS304 stainless steel and equipped with well known Japanese, German, American, Korean or Taiwan brand parts. Either the automatic or semi-automatic Labeling machine is smart and durable labeling equipment which is quite easy for your operation and maintenance. It’s widely used in such industries as food, medicine, cosmetics, electronics, chemical etc.
Application:
The sticker labeling machine is suitable for all kinds of regular and irregular containers.
In addition,you can choose single or double sides labeling.
Features:
Operation |
PLC control system makes labeling machine easy to operate |
Material |
Labeling machine’s main body is made of SUS304 stainless steel |
Configuration |
Our labeling machines adopt Japan motor driving and photo sensor and Taiwan control system |
Flexibility |
Client can chose to add printer, code machine or round bottles mechanism; can connect with conveyer |
Technical Parameters:
Name |
High Speed Double Sides Labeling Machine for Bottles |
Labeling Speed |
60-350pcs/min(Depending on label length and bottle thickness) |
Height of Object |
30-350mm |
Thickness of Object |
20-120mm |
Height of Label |
15-140mm |
Length of Label |
25-300mm |
Label Roller Inside Diameter |
76mm |
Label Roller Outside Diameter |
420mm |
Accuracy of Labeling |
±1mm |
Power Supply |
220V 50/60HZ 3.5KW Single-phase |
Gas Consumption of Printer |
5Kg/cm^2 |
Size of Labeling Machine |
2800(L)×1650(W)×1500(H)mm |
Weight of Labeling Machine |
450Kg |
