24pcs IR leds dome camera 1.0Megapixel ir camera accept paypal CCTV camera
1) CCD: 1/3” SONY CCD
2) Resolution: 420/600//700/ WDR700TVL
3) IR Leds: 24pcs of 5mm IR LEDs
4) IR Range: 10-20M IR Range
5) Lens: 3.6mm/6mm fixed lens
6) Material: Plastic casing
7) IR Auto-open by CDS Control in Low illumination
Technical Parameter:
Model |
KD-ID5024PF |
|||
Horizontal Resolution |
WDR 700TVL |
700TVL |
600TVL |
420TVL |
Effective Pixels (HxV) |
PAL:976×582 |
PAL:976×582 |
PAL:752×582 |
PAL:500×582 |
NTSC: 976x494 |
NTSC: 976x494 |
NTSC:768×494 |
NTSC:510×492 |
|
Signal System |
PAL / NTSC |
|||
Image Sensor |
1/3"SONY 662/663 CCD |
1/3"Sony 810/811 CCD |
1/3"Sony 638/639 CCD |
1/3"Sony 632/633 CCD |
Digital Signal Processor |
SONY Effio-P DSP |
SONY Effio-E DSP |
Nextchip 2090 DSP |
Sony 3142 DSP |
Mini Illumination |
0.02lux(IR on) 0.00lux(IR off) |
0.02lux(IR on) 0.00lux(IR off) |
0.05lux(IR on) 0.00lux(IR off) |
0.01lux(IR on) 0.00lux(IR off) |
Lens |
3.6/6mm fixed lens |
|||
IR LEDs |
5mmX24PCS |
|||
Night Vision |
20M |
|||
OSD |
OSD |
OSD |
OSD |
- |
WDR |
WDR |
D-WDR |
D-WDR |
- |
DNR |
3D-DNR |
3D-DNR |
2D-DNR |
- |
AES |
PAL=1/50 ~1/100,000sec;NTSC=1/60 ~1/100,000sec |
|||
S/N Ratio |
> 48dB(Auto Gain Off) |
|||
BLC |
On/Off |
On/Off |
On |
On |
AGC |
Auto/Manual/Off |
Auto/Manual/Off |
Auto |
Auto |
White Balance |
ATW/Manual/Auto |
ATW/Manual/Auto |
ATW |
ATW |
Video Output |
1.0V P-P,75Ω |
|||
Operating Temperature |
-10 ~ 50℃(relative humidity: max95%) |
|||
Power Voltage |
DC12V±10% |
|||
Suggest Power Adaptor |
DC12V/1A |
|||
Material |
Plastic |
|||
Dimension |
94(W) x94(H) x69(D)mm |
|||
Weight |
300g |
|||
Guarantee |
2 years |
|||
CMOS: |
1/4"PC7030 CMOS Sensor, With IR-Cut |
600TVL |
CMOS: |
1/3"PC3089 CMOS Sensor, With IR-Cut |
700TVL |
CCD: |
1/3" Sharp CCD +Nextchip DSP |
650TVL |
AHD: |
1/4"OV9712 CMOS + NVP2431H DSP |
1.0Megapixel |
The camera effect picture:
Application Places:
Apply to the financial, supermarket, telecommunications, government, schools, airports, factories, hotels, museums and other places of requirement of high-definition.
