Product Details
| Place of Origin: | Guangdong, China | Brand Name: | Kendom | Model Number: | KD-IW3072MV |
| Type: | Other, Analog Camera, Metal Bullet Camera | Style: | Bullet Camera | Sensor: | CMOS |
| Technology: | Infrared | Special Features: | Waterproof / Weatherproof |
Product Description
700TVL Waterproof digital camera 72pcs of 5mm IR LEDs ir bullet camera security camera system
Product Features:
1) CCD: 1/3” SONY CCD,
2) Resolution: 600/ 700/ 700WDR/ 800/ 1300TVL
3) Lens: 2.8-12mm varifocal lens,
4) Material: Aluminium alloy casing
5) IR Auto-open by CDS Control in Low illumination
Application Places:
Apply to the financial, supermarket, telecommunications, government, schools, airports, factories, hotels, museums and other places of requirement of high-definition.
Picture Show:
Technical Parameter:
Model | KD-IW3072MV | |||
Horizontal Resolution | WDR 700TVL | 700TVL | 600TVL | 420TVL |
Effective Pixels (HxV) | PAL:976×582 | PAL:976×582 | PAL:752×582 | PAL:500×582 |
NTSC: 976x494 | NTSC: 976x494 | NTSC:768×494 | NTSC:510×492 | |
Signal System | PAL / NTSC | |||
Image Sensor | 1/3"SONY 662/663 CCD | 1/3"Sony 810/811 CCD | 1/3"Sony 638/639 CCD | 1/3"Sony 632/633 CCD |
Digital Signal Processor | SONY Effio-P DSP | SONY Effio-E DSP | Nextchip 2090 DSP | Sony 3142 DSP |
Mini Illumination | 0.02lux(IR on) 0.00lux(IR off) | 0.02lux(IR on) 0.00lux(IR off) | 0.05lux(IR on) 0.00lux(IR off) | 0.01lux(IR on) 0.00lux(IR off) |
Lens | 2.8-12mm Vari-focal lens | |||
IR LEDs | 5X72PCS | |||
Night Vision | 40-50M | |||
OSD | OSD | OSD | OSD | - |
WDR | WDR | D-WDR | D-WDR | - |
DNR | 3D-DNR | 3D-DNR | 2D-DNR | - |
AES | PAL=1/50 ~1/100,000sec;NTSC=1/60 ~1/100,000sec | |||
S/N Ratio | > 48dB(Auto Gain Off) | |||
BLC | On/Off | On/Off | On | On |
AGC | Auto/Manual/Off | Auto/Manual/Off | Auto | Auto |
White Balance | ATW/Manual/Auto | ATW/Manual/Auto | ATW | ATW |
Video Output | 1.0V P-P,75Ω | |||
Operating Temperature | -10 ~ 50℃(relative humidity: max95%) | |||
Power Voltage | DC12V±10% | |||
Suggest Power Adaptor | DC12V/1A | |||
Material | Aluminium alloy | |||
Dimension | 300(W) x110(H) x90(D)mm | |||
Weight | 1200g | |||
Guarantee | 2 years | |||
Certifications:
Warranty
a.24 Months From Shipping Date;
b.24 Months, any defective product caused by non-artificial reason we will get repaired or replaced for free;
OEM & ODM Services
a. Including Label,Manual,Packages,Logo Printing and Special Outside Color and so on;
Payment Terms
a. Telegraphic Transfer (T/T)
b. Paypal
4% commission charges will be added into the amount;
