Home > Products > Refractory Brick > split de chamota ligera brick
split de chamota ligera brick
- 3000 Ton / Tons per Month
- Qingdao Tianjin Shanghai
- T/T L/C D/P D/A Credit Card
- Shandong supplier fiber reinforced calcium silicate board
- Placa de silicato de calcio 1000 * 500 * 50 mm
- High density thermal insulation material, high-temperature refractory lining
- High density calcium silicate board, carbon fiber, glass fiber
- High density non stick calcium aluminosilicate board
- Cement plant, power plant, aluminum plant, steel plant, chemical plant, metallurgical industry, thermal insulation board
Product Details
Place of Origin: | Henan, China | Shape: | Brick | Material: | Alumina Block |
SiO2 Content (%): | 53& | Al2O3 Content (%): | 42% | MgO Content (%): | less |
CaO Content (%): | less | CrO Content (%): | 0.1~0.3% | ||
SiC Content (%): | 0.00% | Model Number: | split de chamota ligera brick | Brand Name: | DD |
Product Description
split de chamota ligera brick
Fire clay bricks were mainly made from chamotte, flint clay and combining clay powder, being high pressure pressed and sintered in high temperature.
Low porosity bricks are made from low mullite stones, the main mineral composition of the low mullite stones are pressed and sintered mullite phases. The bricks have very good physical and chemical properties in high temperature conditions.
Features and advantages:
1.High refractoriness,
2.High-temperature endurable .
3.Good corrosion resistance.
4.Good spalling resistance and wear resistance.
5.Good thermal shock resistance.
6.High mechanical strength.
7.High-temperature creep rate is low.
8.Good volume stability at high temperature.
split de chamota ligera brick
Item | ZGN-42 | GN-42 |
AL2O3 /% | ≥42 | ≥42 |
Fe2O3 /% | ≤1.6 | ≤1.7 |
Refractoriness /°C | ≥1750 | ≥1750 |
Apparent porosity/ % | ≤15 | ≤16 |
Cold crushing strength/ Mpa | ≥58.8 | ≥49.0 |
Refractoriness under load/ °C | ≥1450 | ≥1430 |
Reheating Linear Change(1450°C,2h)/% | 0 -0.2(3h) | 0 -0.3(3h) |
Permeability | This test must be conducted.The data of the test shall be included in the quality certificate |
High density chamotte firebrick Applications
High density chamotte firebrick are mainly used in the low temperature parts of blast furnaces, waste incinerators and glass melting furnaces. Due to the scale-up of a variety of industrial furnaces and severity of operating conditions, super dense clay bricks that made of more refined chamotte being calcinated at high temperature are applied more than before. It's popular in the following furnaces:
1. Blast furnaces and hot blast furnaces
2. Waste incinerators
3. Glass melting furnaces
split de chamota ligera brick
High density chamotte firebrick Common shape:
refractory bricks:230X114X75mm,230X114X65mm, etc. As requested
refractory tiles:230x114x32mm,230x114x40mm,230x114x50mm, etc. As requested
refractory slabs :300X400X75mm,etc. As requested
High density chamotte firebrick Shape:
Side arch bricks: 230x114x75/70mm,230x114x75/65mm,230x114x75/50mm,etc.As requested.
End wedge bricks:230x114x75/70mm,230x114x75/65mm,etc.As requested
High density chamotte firebrick Special Size
refractory tiles: 200x100x50mm,200x100x75mm,220x110x30,230x115x32mm,250x123x32mm,
465x115x65mm, etc. As requested
Refractory bricks: 220x110x60mm,230x115x65mm,230x115x75mm,230x150x65mm,230x150x55mm,
230x172x75mm,220x165x60mm,230x172x65mm,250x187x65mm, etc. As requested
Side arch bricks: 230x172x112/88mm,230x172x106/94mm,230x172x100mm ,etc.As requested
Refractory double bricks:220x220x60mm,230x230x65mm,250x250x65mm,etc.As requested
split de chamota ligera brick
Chamotte firebrick Packaging:
1. On wooden pallets with plastic cover;
Wooden pallet size: 1000*1000*1000mm load weight of each pallet: 1.6-2.0 tons
2.Shipping by 20Ft container.
For more details of our products and others,please kindly contact us!
3. We will do our best to avoid the goods damage and secure your goods in transportation.
At Dengda, our goal is to make the exact refractory tile the way you want. We are unique from anyone else in that we make every tile to order using recycled materials and sustainable manufacturing practices. We focus on working directly with you to create the residential and commercial project of your dreams, all in a timely manner and with the greatest customer service in the world.
The advantages of our company:
1. High quality: Strict quality control and more than 20 years experiences.
2. Competitive price: Directly from our factory to your hands without other traders.
3. Good packaging: Avoid damage and secure your goods in transportation.
4. Quick response: Your any questions will be replied within 24 hours.
5. Professional technology: The size, density, chemical composition can be customized.
6. Geographical advantage: Our factory is located in Zhengzhou Henan province, which is one of the main refractory production bases in China. we have abundant resources and high quality minerals. This favorable condition reduce the cost to save you money.
7. Timely delivery: 25 days after receiving deposit.
8. Samples are free.
