Joystick & Game Controller Pcb

Shenzhen Shenyixin Electronics Co., Ltd.

US$ 0.01 - 5 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

SYX-F165

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name OEM

Model Number SYX-F165

Number of Layers 8-Layer

Base Material FR-4

Copper Thickness 35UM

Board Thickness 1.6MM

Min. Hole Size 0.1MM

Min. Line Width 3mil

Min. Line Spacing 3mil

Surface Finishing ENIG

Item	Manufacture Capability
Material	FR4/ Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminum, Metal based/FR1/CEM1/FPC
Layer No.	1-- 20
Finished Board thickness	0.2 mm-4.0mm’(8 mil-160 mil)
Board Thickness Tolerance	±10%
Cooper thickness	0.5 OZ-6OZ (18 um-210 um)
Copper Plating Hole	18-40 um
Impedance Control	±10%
Warp &Twist	0.50%
Peelable	0.012"(0.3mm)-0.02’(0.5mm)
Images
Min Trace Width	0.075mm (3mil)
Min Space Width	0.075mm (3mil)
Min Annular Ring	0.1mm (4 mil)
Solder Mask
Min Solder Mask Dam	0.0635 mm (2.5mil)
Solder mask Clearance	0.1mm (4 mil)
Holes
Min Hole size (CNC)	0.1 mm (4 mil)
Min Punch Hole Size	0.9 mm (35 mil)
Hole Size Tol (+/-)	PTH:±0.075mm;NPTH: ±0.05mm
Hole Position Tol	±0.075mm
Plating
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel 3-7um Au:1-5u''
OSP	0.2-0.5um
Certificate	ROHS, SGS, UL, ISO9001: 2008,TS16949
