Specifications
automatic bottle washing filling capping and label plant2.ONE YEAR WARRANTY
3.WOODEN/FILM
4.PLC
5.SUS 304
automatic bottle washing filling capping and label plant
1.application: automatic bottle washing filling capping and label
2.capacity:2000b/h-20000b/h
3.packaging :film&wooden
4.bottle type:PET
DCGF Automatic 3 in 1 bottled soft drinking water filling machine(CE AND ISO certificate)
3 in 1 set is used for bottled soft water filling. Eg. Coca cola, sprit or other soda water filling.
Automatic filling machine combines washing, filling and cover sping with complete automatic, suitable for aerated water filling into polyesterand PET bottles. It can be used for all kinds of bottles. The bottleneck blocking makes the process of changing bottles easy by only adjusting the height of conveyor chain.
Features
1. Capacity: 2000bph-20000bph, 500ml-2L
2. Automatic rotary rinser, filler and capper
Configurations
3. Human Machine Interface
4. Imported top brand Components
Mitsubish programmable PLC touch screen control
5. Airtac pneumatics
6. Schneider Eletric
Main Technical Specifications
Model |
18-18-6 |
24-24-8 |
32-32-12 |
40-40-15 |
50-50-18 |
Productivity(500ml) |
5000 |
8000 |
10000 |
13000 |
15000 |
Filling precision |
≤± less or equal in5mm(liquid level positioned) |
||||
Filling pressure |
≤0.4 |
||||
PET Bottle Size(mm) |
Diameters 50-100 ; Height: 150-310 |
||||
Suitable Cap Size |
Plastic screw lid |
||||
Power(KW) |
3.1 |
3.1 |
5.6 |
7.5 |
9 |
Weight(Kg) |
3500 |
4500 |
5500 |
9000 |
12000 |
Overall Dimension(mm) |
2400×1900×2300 |
2800×2100×2300 |
4200×2300×2300 |
5000×2800×2400 |
5900×3100×2400 |
