1. Overview -- On Metal Passive UHF RFID Tag
The UHF RFID tag provides totally new benchmark for low-cost passive UHF on metal tag to various customer requirements. The UHF RFID tag can be mounted easilly on any metallic surfaces either with industrial adhesive or mechanically elg. with pop rivets. the performace enables sveral on-metal identificaiton challenges to be solved which earlier where impossible with passive RFID. The UHF RFID tag have passed series reliability tests. It does used successfully in Europe, America and Asia for tracking assets from steel pallets to equipments.
2. Production Description
2.1 Typical Features
- On metal passive UHF RFID tag.
- Long read range.
- Flexible installation.
- Function reliable .
2.2 Application
- Ideal for asset tracking applications like laptops, tablets, Television, refrigeratory, washing machine etc. home application, steel pallets and equipments.
- Management for fork truck management.
- Management for big size tank , metal pipes, or valves.
2.3 Functional Specifications
Air Interface Protocol |
EPC Class1 Gen2, ISO18000-6C |
Operational Frequency |
860 - 960MHz |
IC Options |
Alien H3, H4 |
EPC Memory |
96bits, Extensible to 480bits |
User Memory |
512bits |
Functionality |
Read/ Write (User programmed) |
Data Retention |
10 years |
Warranty (Limited) |
1 year |
Applicable Surface Materials |
Metal surfaces |
2.4 Physical Specification
Material |
FR4, anti-metal layer |
Color |
Black , blue or silver , any color is possible |
Dimensions |
100* 25* 3mm (3.937* 0.984*0.118in) |
Operational Temperature |
-30 °C to 80 °C |
Storage Temperature |
-40 °C to 95 °C |
Peak of Temperature |
150 °C, hours 110 °C, days |
Humidity |
5% - 95% |
Weight |
18 g |
Package |
100 pcs/ small box, 1000 pcs/ carton |
2.5 Reliability Specification
Impact Test |
5kg from 1m, Pass |
Fall Test |
200 times from 1m, Pass |
Alcohol Test |
Pass |
Gasoline Test |
Pass |
Temperature Shock |
-40 °C to 150 °C (5 hours/cycle, 30 cycles) |
RoHS |
RoHS compliant |
IP Class |
IP63 |
3. Packaging & Shipping
3.1 Packaging
100 pcs/box, 10boxes/ carton, 1000pcs/ carton
18g /pcs, 1.8kg/box, 18kg/ carton
3.2 Shipping
Deliveried by FedEx, UPS, DHL or by air , by sea
4. Our Services
4.1 Can OEM and ODM of metal UHF RFID tag.
4.2 Can customize RFID tags per the requirements of customers.
4.3 Strickly control in the reliabilities and the consistency of functions.
4.4 Can provide the technology support of tags for customer's projects.
