High efficiency 3 gallon barrel filling machine/Hot sale 5 gallon filling
5Gallon Filling Machine
5Gallon Beverage Machine ,water filling machine
5Gallon Filling Machine
This filling line specially produces 5 gallons filling dinking water, whose types (b/h) are: 100 type, 200 type, 300 type, 450 type, 600 type, 900 type, 1200 type and 2000 type.
1. It integrates bottle washing, filling and sealer into unit, Multiple injections of washing and sterilizing and bleaching are used in bottle.
2. The sealer can seal bottle caps qutomatically.
3. The 5 Gallon filling machine equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.5Gallon Filling Machine
images show:
Technique parameter:
| Main Technical parameters | |||||||
| Model | QGF-100 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 | QGF-2000 |
| Filling heads | 1 | 2 | 3 | 4 | 8 | 12 | 16 |
| volume(L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| Barrel size(mm) | φ 270× 490 | φ 270× 490 | φ 270× 490 | φ 270× 490 | φ 270× 490 | φ 270× 490 | φ 270× 490 |
| Capacity(b/n) | 100-120 | 200-240 | 300-400 | 600 | 900 | 1200 | 2000 |
| Gas pressure(mpa) | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Gas consumption(m 3 /min) | 0.37 | 0.6 | 0.6 | 1.2 | 2.2 | 3 | 4.5 |
| Motor power(kw) | 1.75 | 3.22 | 4.8 | 8.5 | 8.5 | 8.5 | 8.5 |
| Rated voltage(V) | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Outline dimension(mm) | 3790× 650 × 1550 |
3550× 800 × 1800 2800× 1100 × 1800 |
3550× 1200 × 1800 3800× 1100 × 1800 |
3650× 1500 × 1800 3800× 1100 × 1800 |
2200× 1860 × 2700 |
2560× 2350 × 2750 |
3100× 2800 × 2750 |
| Weight(kg) | 800 | 2800 | 4000 | 5500 | 7500 | 9500 | 11800 |
Certificates:
Factory and workshop:
working:
Packing:
Keyuan would like to move forward together with you and will spare no effort.Any question about this machine ,contact us please ,sincere service for you .
Welcome to KEYUAN!
------------------------------------------------------------------------
After sales service:
1.One year warranty for the whole system.
2.We can send our engineers/technicians for installation of entire production line . Should make sure the safety of our
engineers.
3.After one year , we can help you to maintain the machine and the accessories are provided only one the cost price.
4.Every 3 year , we can help to overhaul the machine freely (labor).
5.We can provide internship service and help you train the operator and mechanic.
6.Free production technology and process configuration.
6.We can help you to design the product line , workshop and provide turn-key project.
7.How to get your suitable machine or production line ?
8.Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trademanager, MSN, Skype) and let us know your
enquiry.
9.Discussion: Specify the items you desire, confirm specification; OEM/ODM consultation.
10.Quotation: Prices offered and accepted.
11.Place order as per contract or discussion.
12.Perform invoice( sales contract ) In duplicate confirmed and kept by both sides.
13.Payment settled.
14.Order completed under our arrangement.
15.Goods shipped as per contracted term.
16.Goods arrive at local port or warehouse, depending on contracted term.Support & re-ordering.
Any question about 5 Gallon Bottle Washing&filling&capping/gallon water filling machine ,contact with us please,sincere service for you and welcome to zhangjiagang keyuan!
