Specifications
automatic beverage mixer1.one year warranty
2.small
3.easy to control
4.SUS304
automatic beverage mixer
Specifications
This auto injecting gas-water mixer is specially designed for soda and non-soda drinks such as lemonade, cola and juice.
The pre-cooled and pre-carbonized liquid flows through the inlet valve into the pot, in which, there is carbonic acid gas as well. The liquid flows out the groove and turns into a liquid curtain for better cooling and good carbonic acid gas absorption. Finally, the treated beverage liquid, powered by the carbonic acid gas pressure, flows into the filling machine.
Quality materials are used for this machine. Especially polished and sanitary steel is used for parts directly contacting the liquid. The machine is designed for various beverage productions. Besides the two-step carbonization, high CO2 content and low production temperature ensures the volume ratio of CO2 and 1L water to be 3.5 to 4.0, or higher.
| Model |
QHS-1500 |
QHS-2500 |
QHS-3500 |
QHS-5500 |
| Production Capacity(kg/h) |
1000-1500 |
2000-2500 |
3000-3500 |
5000-5500 |
| Mixing production scale (water:sugar) |
3:1-6:1 |
3:1-6:1 |
3:1-6:1 |
3:1-6:1 |
| content of carbon dioxide |
2.5-3.5 |
2.5-3.5 |
2.5-3.5 |
2.5-3.5 |
| Mixing temperature |
<5 |
<5 |
<5 |
<5 |
| power consumption (kw) |
1.5 |
2.97 |
3 |
5 |
| Overall Size(mm) |
1000×800×2000 |
1500×1000×1900 |
1700×1000×2200 |
2000×1500×3000 |
when you send inquiry,please also included the capacity you need to work on the machine, it is easy and accurately for us to recommand a right machine!
If any special,our manufacture also can design the machines according your requirement.
1.Products since the acceptance inspection, one year warranty, life-long maintenance;
2.Free for the buyer personnel to technical training, (or on-site technical training)
3.The quality problem or the supplier of parts and equipment damage caused by careless operation and equipment failure, the 4.Supplier provide high quality, favorable service;
Zhangjiagang Keyuan Machinery Co., Ltd. is a modern technical enterprise set up to meet the 21st century's development demand regarding beverage packing machinery and all sorts of water treatment facilities. Our company has production experience of more than 20 years. Our company is a professional enterprise producing full sets of beverage packing machinery and all sorts of water treatment facilities, integrating product development, scientific research & design, production, technical service and marketing.
At present, our company provides the following production lines:
Complete sets of gas containing drink production lines
Complete sets of Mineral water and spring water production lines
Complete sets of Pure water production lines
Complete sets of Fruit juice production lines
Bean milk & protein drink production lines
Complete sets of white spirit, soy and vinegar filling production lines
Keyuan would like to move forward together with you and will spare no effort. Welcome to Keyuan
