21.5 inch desktop touch all in one PC

Case/Bezel Color

Silver or Black

Display Size

21.5"

LCD Type

LED Backlight

Aspect ratio

16:9

Useful Screen Area

476.64 x 268.11mm

Touch panel

Multi Flat_touch Projected Capacitive

Touch response time

10ms

Touch Monitor Dimensions

524.0 x 332.0 x 60mm

Optimal (native) Resolution

1920 x 1080

LCD panel Pixel pitch

0.24825x 0.24825mm

LCD panel Colors

16.7M

LCD panel Brightness

250 cd/m2

LCD panel Response Time

5ms

Viewing Angle

(typical, from center)

Horizontal (left/right)

±80° or 160°

Vertical (up/down)

±80° or 160°

Contrast Ratio

1000:1

ECM

(Embed Computer Modul)

ECM1: Intel® processor P7500 (1.8GHz Dual Core);

ECM2: Intel® processor P7550 (2.26GHz Dual Core); HardDisk:320G;Rom:2G(DDR3,max6G);           Operation System:Win7XpVistaLinux

ECM3: Android A8 1.5G, Flash 4G

ECM4: Android dual core 2G, Flash 4G

Operation System: 4.04

Speaker

2*10W(optional)

Input interface

2*USB, 1*Power

Power Supply Type

External AC input,built-in power brick

Power Dissipation: 60W

Temperature

Operating: 0°C to 40°C; Storage -20°C to 60°C

Humidity (non condensing)

Operating: 20%-80%; Storage: 10%-90%

Shipping Carton Dimensions

616x456x206mm

Weight (approx.)

Actual:8 kg; Shipping: 10 kg

Warranty Monitor

3 years(Except for LCD panel and PC 1 year)

Backlight lamp life: typical 50,000 hours to half brightness

Agency Approvals

CE/FCC/Rohs

Mounting Options

75 mm or 100 mm VESA mount
