Gaming pc

Gaming pc thumbnail-1
Gaming pc photo-1
US$ 256 - 686 MOQ: 1 Unit
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
All-In-One
Screen Size:
Other, 15"
Contact Supplier Request Quote Chat Now
Chengdu Zenghong Sci-Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type All-In-One
Screen Size Other, 15"
Processor Brand Intel
Memory Capacity Other, 2GB/4GB
Hard Drive Capacity 320GB
Graphics Card Type Integrated Card
Display Type LCD
Widescreen No
Processor Main Frequency 1.2GHz-2.7GHz
Brand Name TouchDisplays
Model Number 1515E-IDT
Place of Origin Sichuan, China

Specifications

gaming pc
-Multilingual on-screen display-OSD
-Touch flat screen
-SAW or projected capactive

1515E 15" LCD Desktop Flat-Touch PC Monitor


     gaming pc

Features

Small footprint,retail-hardended,flexible touchcpmputer

800:1 contrast ratio, and 400-nit brightness (LCD panel)

Surport secend display extend

Zero-bezel multi-touch screen

Removable base and VESA mounting option

Mounting holes on base bottom for tabletop security

optional Front bezel be sealed IP64

Optional ergonomic 3 stripe MSR available

Full range of standard connectivity ports for retail POS and hospitality

applications

Projected Capacitive Technology and Surface Accoustic Wave Technology

Excellent cable management and cables hidden from view

Applications

Countertop kiosk information systems      Gaming and amusement

Point-of-sale (POS)                      Point-of-information

Accessories

Power Cord (US, EU or UK type)

Power Brick                User Manual (English only)

gaming pcgaming pcgaming pcgaming pc

Specifications

Model

1515E-IDT

Case/Bezel Color

Black/Silvery/white(Cistomized)

Display Size

15.0"

Style

True Flat

Touch panel

Projected Capacitive touch screen (SAW touch screen optional)

Touch response time

8ms (PCT typical) and 10ms(SAW typical)

Touchcomputors Dimensions

372x 212 x 318 mm(with stand);372x 56 x 318 mm(without stand)





LCD Type

TFT LCD(LED backlight)

Useful Screen Area

304 mm x 228 mm

Aspect ratio

4:3

Optimal (native) Resolution

1024 x 768

LCD panel Pixel pitch

0.297 x 0.297 mm



LCD panel Colors

16.7 million

LCD panel Brightness

400 cd/m2 (high brightness customized upto 1000 cd/m2)

LCD panel Response Time

30 ms

Viewing Angle

(typical, from center)

Horizontal (left/right)



±80° or 160° total

Vertical (up/down)

±80° or 160° total

Contrast Ratio

800:1

output Video signal connector

Mini D-Sub 15-Pin VGA type and HDMI type

Input interface

usb 2.0*4(usb 3.0*2 optional)PCI-E(3G SIM card,wifi and bluetooth optional)

Earphone*1Mic*1Com*3RJ45*1

Extend interface

USB2.0*4Com*21*PLTHdd&SSD&CF Card external interface

Power Supply Type

Monitor input: +12VDC ±5%,4.0 A; DC Jack (2.5F)

AC to DC power brick input: 100-240 VAC, 50/60 Hz

Power Comsuption: 48W max



 ECM

(Embed Computer Modul)

ECM1: Intel® processor D2550 (Dual Core 1.86GHz,Fanless);

ECM2: Intel® processor D2700 (Dual Core 2.13GHz,Fanless);

ECM3: Intel® processor P7550 (Dual Core 2.26GHz,Fan-cool);

ECM4: Intel® processor i3 2310M(Dual Core 2.1GHz, Fan-cool);

ECM5: Intel® processor i5 2410M (Dual Core 2.3GHz/2.9GHz Turbo, Fan-cool);

ECM6: Intel® processor i7 2620M (Dual Core 2.7GHz/3.4GHz Turbo, Fan-cool);

HDD:320G(500G-1TB optional);SDD:32G(upto 128G optional);CF Card 32G(upto 128G Optional); Memory: DDR3 2G(upto 8G);

Operation System:Win7win8XpwinCEVistaLinux

ECM7: Android dual core 1.5G, Rom 1G,Flash 4G

ECM8: Android quad-core 1.2G,Rom 1G, Flash 4G

Operation System: 4.2.2

Temperature

Operating: 0°C to 40°C ;Storage -20°C to 60°C

Humidity (non condensing)

Operating: 20%-80%; Storage: 10%-90%

Shipping Carton Dimensions

556 x 206 x 456 mm(with stand);470 x 210 x 420 mm(without stand)

Weight (approx.)

Actual: 6.8 kg ;Shipping: 8.2 kg

Warranty Monitor

3 years(Except for LCD panel 1 year)

Backlight lamp life: typical 50,000 hours to half brightness

Agency Approvals

CE/FCC Rohs

Mounting Options

75 mm and 100mm VESA mount
