SAW touch screen optional android pos terminal pos software
Product Overview |
Product Picture & Specification |
| Case/Bezel Color | Black/Silvery/white(Cistomized) | |
| Display Size | 15.0" | |
| Style | True Flat | |
| Touch panel |
Projected Capacitive touch screen (SAW touch screen optional) |
|
| Touch response time | 8ms (PCT typical) and 10ms(SAW typical) | |
| Touchcomputors Dimensions |
372x 212 x 318 mm(with stand); 372x 56 x 318 mm(without stand) |
|
| LCD Type | TFT LCD(LED backlight) | |
| Useful Screen Area | 304 mm x 228 mm | |
| Aspect ratio | 4:03 | |
| Optimal (native) Resolution | 1024 x 768 | |
| LCD panel Pixel pitch | 0.297 x 0.297 mm | |
| LCD panel Colors | 16.7 million | |
| LCD panel Brightness |
400 cd/m2 (high brightness customized upto 1000 cd/m2) |
|
| LCD panel Response Time | 30 ms | |
|
Viewing Angle (typical, from |
Horizontal | ±80° or 160° total |
| Vertical | ±80° or 160° total | |
| Contrast Ratio | 800:01:00 | |
| output Video signal connector | Mini D-Sub 15-Pin VGA type and HDMI type | |
| Input interface | usb 2.0*4(usb 3.0*2 optional)PCI-E(3G SIM card, wifi and Bluetooth optional) | |
| Earphone*1Mic*1Com*3RJ45*1 | ||
| Extend interface |
USB2.0*4Com*21*PLTHdd&SSD &CF Card external interface |
|
| Power Supply Type | Monitor input: +12VDC ±5%,4.0 A; DC Jack (2.5) | |
| AC to DC power brick input: 100-240 VAC, 50/60 Hz | ||
| Power Consumption: 48W max | ||
|
ECM (Embed Computer Modul) |
ECM1: Intel® processor D2550 (Dual Core 1.86GHz,Fanless); |
|
|
ECM2: Intel® processor D2700 (Dual Core 2.13GHz,Fanless); | ||
|
ECM3: Intel® processor P8600 (Dual Core 2.4GHz,Fan-cool); | ||
|
ECM4: Intel® processor i3 2310M (Dual Core 2.1GHz, Fan-cool); | ||
|
ECM5: Intel® processor i5 2410M (Dual Core 2.3GHz/2.9GHz Turbo, Fan-cool); | ||
|
ECM6: Intel® processor i7 2620M (Dual Core 2.7GHz/3.4GHz Turbo, Fan-cool); | ||
|
HDD:320G(500G-1TB optional); SDD:32G(up to 128G optional); | ||
|
CF Card 32G(up to 128G Optional); Memory: DDR3 2G(up to 8G); | ||
| Operation System:Win7Win8XPWinCEVistaLinux | ||
| ECM7: Android dual core 1.5G, Rom 1G,Flash 4G | ||
| ECM8: Android quad-core 1.2G,Rom 1G, Flash 4G | ||
| Operation System: 4.4.2 | ||
| Temperature | Operating: 0°C to 40°C ;Storage -20°C to 60°C | |
| Humidity (non condensing) | Operating: 20%-80%; Storage: 10%-90% | |
| Shipping Carton Dimensions |
556 x 206 x 456 mm(with stand); 470 x 210 x 420 mm(without stand) |
|
| Weight (approx.) | Actual: 6.8 kg ;Shipping: 8.2 kg | |
| Warranty Monitor | 3 years(Except for LCD panel 1 year) | |
| Backlight lamp life: typical 50,000 hours to half brightness | ||
| Agency Approvals | CE/FCC RoHS | |
| Mounting Options | 75 mm and 100mm VESA mount | |
Drawings |
Production Flow |
More POS Terminal to Choose |
Company Profile |
Together with US |
Certifications |
Packaging design |
| Our Service |
|
On-Time Delivery: Full refund if product isn't received in guaranteed delivery time Returns & Refund: Full refund if product isn't received in guaranteed delivery time Longer Protection: 15 days more protection after order completion Returns Extra: Return any prodct,only those in perfect condition Guaranteed Quality: Guaranteed quality of full refund Payment: We accept: T/T, Wester union, Paypal. T/T payment, It is available for any orders once the value more than $800.00. Wester union payment, It is available for any orders. Shipment : We ship worldwide by EMS, DHL, UPS, FedEx, TNT, China Post, E-packet, Singapore Post,Hong Kong Post and so on. We are unable to control the delivery time because it is processed by Third-party service, but if the parcel has not arrive within expected time, please contact us, we will help you to track it and give you a satisfied reply.
If you are staisfied with our product and service, Please leave Us postive feedback & a 5 star review!
We are looking forward to establishing a long-term partnership with you!
|
