Home > Industrial Equipment & Components > Welding Equipment > Plastic Welder > Tarpaulin Auto Step High Frequency Canvas Welding Machine
Tarpaulin Auto Step High Frequency Canvas Welding Machine
US$ 30,000 - 58,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Sinopwr
Model Number:
ZG-25KW-AF
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Frequency Outdoor Signs Auto Step hf WelderUS$ 18,000 - 27,000MOQ: 11 Sets -
PVC Fabric Sealing 10000w High Frequency Welding MachineUS$ 1,000 - 30,000MOQ: 1 Unit
-
PET Material American System Ultrasonic Plastic WelderUS$ 1,000 - 9,000MOQ: 1 Unit
-
20khz American Style Ultrsonic Welding MachineUS$ 1,000 - 9,000MOQ: 1 Unit
-
15Khz American Standard Ultrasonic Plastic Weld MachineUS$ 1,000 - 9,000MOQ: 1 Unit
Place of Origin
Guangdong, China
Brand Name
Sinopwr
Model Number
ZG-25KW-AF
Voltage
380V
Power
25KW
Frequency
50/60HZ
Welding Area
according to sample
Dimensions
160*800*170
Weight
about 1100KG
Usage
Tarpaulin Soldering
After-sales Service Provided
Engineers available to service machinery overseas
Tarpaulin auto step high frequency canvas welding machine
Product Description
This series HF welders is equipped with special deep and wide trough behind the electrode for material storage and handling. Machine has smooth glide wheels for easy movement inaround welded fabric, or relocation to a desired place in manufacturing hall.
Main application:
Small and large format technical textiles PVC or PU coated
Single weld cycles up to 600cm2 welded area (line or curved shape)
Tensile structures, tents, shade systems, truck covers and side curtains,
Swimming pool liners and covers, oil booms, flood dams and water tanks
Airport hangars, portable storage structures, containment pools, ground liners
Advertising signs and large format billboards
Specification:
| Model | ZG-15KW-AF | ZG-25KW-AF | ZG-35KW-AF |
| Power | 15KW | 25KW | 35KW |
| Input power | 25KVA | 35KVA | 50KVA |
| Voltage | 3Phase 220v/380V 50/60HZ | ||
| Frequency | 27.12MHz | ||
| Rectifier | silicon diode | ||
| Oscillation tube | 8T85RB | 8T25RB | 8T87RB |
| Max pressure | 600kg | 1000kg | 1500kg |
| Operation mode | pneumatic | ||
| Max distance of electrodes | 160mm | ||
| The press stroke | 150mm | ||
| The size of upper electrode | 100*1000mm | 100*1200mm | 100*1500mm |
| Length of working table | 6000mm | ||
| Length of welding | 5-10meter/min | ||
| The range of temperature | 30~200 °C adjustable | ||
| Welding time | 0---30s adjustable | ||
| Productivity | < 360times/hour | ||
| Note:the length can be added, 3 meters/section | |||
