RF tarpaulin welding machine rf canvas pvc ceiling machine
HF Welder is designed specifically for production of small and large format tensile structures, membranes, tarpaulin, tents, oil booms, truck covers, swimming pool liners & covers, airline hangars, large billboards, fast doors, side curtains, etc.
We are manufacturer of high frequency welding machine known as radio frequency welding machine, welding machine, soft creased line plastic box making machine and blister packing machine, plastic welding machine and cylinder tube making machines etc. We also could provide the best solution for your customized plastic wleding machine based on your products needs.
This series HF welders is equipped with special deep and wide trough behind the electrode for material storage and handling. Machine has smooth glide wheels for easy movement inaround welded fabric, or relocation to a desired place in manufacturing hall.
Main application:
Small and large format technical textiles PVC or PU coated
Single weld cycles up to 600cm2 welded area (line or curved shape)
Tensile structures, tents, shade systems, truck covers and side curtains,
Swimming pool liners and covers, oil booms, flood dams and water tanks
Airport hangars, portable storage structures, containment pools, ground liners
Advertising signs and large format billboards
Specification:
| Model | ZG-8KW-F1 | ZG-10KW-F1 | ZG-12KW-F1 | ZG-15KW-F1 | ZG-25KW-F1 |
| Power | 8000W | 10KW | 12KW | 15KW | 25KW |
| Input power | 15KVA | 18KVA | 20KVA | 25KVA | 35KVA |
| Voltage | 3Phase 220v/380V 50/60HZ or customized | ||||
| Frequency | 27.12MHz | ||||
| Rectifier | silicon diode | ||||
| Oscillation tube | 7T69RB | E3069 | 3130RB | 8T85RB | 8T25RB |
| Max pressure | 400kg | 600kg | 750kg | 1000kg | 1200kg |
| Operation mode | pneumatic | ||||
| Max distance of electrodes | 150mm | ||||
| The press stroke | 150mm | ||||
| The size of upper electrode | 100*700mm | 100*800mm | 100*900mm | 100*1000mm | 100*1200mm |
| The size of lower electrode | 450*900mm | 450*950mm | 450*1050mm | 450*1150mm | 450*1350mm |
| deep of throat | 500-650mm | ||||
| The range of temperature | 30~200 °C adjustable | ||||
| Welding time | 0---10sdjustable | ||||
| Suitable welding area | 100cm2 / 200cm2 / 250cm2 / 280cm2 / 320cm2 / 500cm2 / 700cm2 |
||||
