15inch Monitor With Wifi Controller

Case/Bezel Color

Steel/black

Display Size

15.0"

LCD Type

TFT LCD

Aspect ratio

4:3

Useful Screen Area

304 mm x 228 mm

Monitor Dimensions

333 x 261 x 39 mm

Optimal (native) Resolution

1024 x 768

LCD panel Pixel pitch

0.297 x 0.297 mm

Plug and Play

VESA DDC 1/2B

LCD panel Colors

16.2 million

LCD panel Brightness

250 cd/m2

LCD panel Response Time

8 ms

Viewing Angle Horizontal (left/right)

±75° or 150° total

(typical, from center) Vertical (up/down)

70°(up), 60°(down) or 140° total

Contrast Ratio

500:1

Input Video Signal Connector

Mini D-Sub 15-Pin VGA type and DVI type(optional)

Input Frequency Horizontal Vertical

31.5-80.0 kHz 60-75 Hz

Power Supply Type

External AC to DC power brick

Monitor input: +12VDC ±5%,4.0 A ;DC Jack (2.5)

AC to DC power brick input: 100-240 VAC, 50/60 Hz

Power dissipation: 48W max

On-screen display(OSD)

Controls(back):Power,Menu,Up,Down,Auto;

Settings: contrast, brightness, H/V position;

RGB(color temp),clock, phase, recall;

Languages: English, German, French ,Spanish, Japanese;

Temperature

Operating: 0°C to 40°C ;Storage -20°C to 60°C

Humidity (non-condensing)

Operating: 20%-80%; Storage: 10%-90%

Shipping Carton Dimensions

556 x 456 x 206 mm

Weight (approx.)

Actual: 3 kg ;Shipping: 5.5 kg

Warranty

1 years

Backlight lamp life: typical 50,000 hours to half brightness

Agency Approvals

CE/FCC Rohs

Mounting Options

75 mm or 100 mm VESA mount
