HUIYUAN glass optic fiber patch cord
INTRODUCTION
Smart GOF Patch Cord is designed for those who need to pick up one faulted cable from thousands of possible cables.
This pruduct uses a GOF fiber as the communication transmission medium, and a POF fiber as the recognition and detection medium. Each Patch Cord has two high-precision ceramic ferrule connectors.
One can easily recognize one of the cable's ends through inputting visible light source from the other end.
FEATURES
Instant and accurate recognition of cables
Simple detection operation, few maintenance
Length of patch cord is up to 300 meters (identify with blue and green light)
Anti-electromagnetic interference and electromagnetic radiation
Heat and cold resistant
Good fire-protection rating
Low insertion loss, high return loss, good swap performances and repeat plug performances
Meet the requirements of adaptability in ANSI / TIA / EIA and ISO / IEC and other rough environments
Stable environmental features, reach the Telcordia standards
TECH SPECIFICATION
| Parameters | Numerical value | ||||
| Connector | SC & SC | ||||
| Fiber type | SM / MM | ||||
| POF diameter | 1mm | ||||
| Cable diameter | 2.5mm×1.6mm | ||||
| Standard length | 1m (can be customized) | ||||
| Cross section | PC | UPC | APC | PC | UPC |
| Insertion loss | ≤0.20dB | ≤0.30dB | ≤0.20dB | ≤0.40dB | |
| Return loss | ≥45dB | ≥50dB | ≥60dB | ≥45dB | ≥50dB |
| Operating temperature | - 40℃ ~ + 75℃ | ||||
| Storage temperature | - 40℃ ~ + 85℃ | ||||
| Operating wavelength | 850nm,1310nm,1550nm | ||||
| Durability | ≥1000 times | ||||
