Building Machinery Liquid Mix Agitators for Building Materials
US$ 1,000 - 999,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Planetary Mixer
Product Type:
Other, Slurry mixing
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai qingdao dalian etc
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Industrial Gold Magnetic Separator Machine From ShangHai LipuUS$ 1,000 - 99,999MOQ: 1 Set -
Ciment Mixer Machines Vertical Agitator Building Machine SuppliersUS$ 1,000 - 999,999MOQ: 1 Set
-
High Frequency Mining Vibrating Screen SeparatorUS$ 1,000 - 999,999MOQ: 1 Set
-
China Wet Drum Type Magnet Separator for River SandUS$ 1,000 - 99,999MOQ: 1 Set
-
China 10-120 TPH Intensity Adjustable Magnetic SeperationUS$ 1,000 - 99,999MOQ: 1 Set
Condition
New
Mixer Type
Planetary Mixer
Product Type
Other, Slurry mixing
Application
Other, Liquid with Suspended Solids, Mix drug and slurry
Additional Capabilities
Granulating
Place of Origin
Shanghai, China
Brand Name
LIPU
Model Number
XB series
Max. Loading Capacity
0.098-30m3
Voltage
According to model
Power(W)
1.5-30kw
Dimension(L*W*H)
According to capacity
Certification
ISO9001:2000
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
liquid mix agitators:1.Model:XB series;
2.Volume:0.098-30 m3;
3.Internal diameter:500-2500mm;
4. Application:mix slurry,etc
Brief Introduction Of liquid mix agitators :
Blender For Ore Exploiting is mainly used to mix slurry before flotation in the beneficiation process. It can mix drug and slurry completely. It is suitable to mix slurry with density smaller than 30 % (weight ratio) and size smaller than 1mm. V-belt of motor drives impeller to mix drug and slurry completely. This machine can increase reaction time and strengthen reaction quality of the drug.
Product parameter of liquid mix agitators :
| Model | Internal diameter (mm) | Internal Height (mm) | Volume (m3) | Impeller speed (r/min) | Impeller diameter (mm) | Weight (t) | Motor power | Dimension (LxWxH) (mm) | |
| Model | Power(KW) | ||||||||
| XB-500 | 500 | 500 | 0.098 | 600 | 200 | 0.15 | Y90S-6 | 1.1 | 600×566×954 |
| XB-750 | 750 | 750 | 0.33 | 530 | 255 | 0.6 | Y90L-4 | 1.5 | 1131×880×1241 |
| XB-1000 | 1000 | 1000 | 0.58 | 530 | 255 | 0.99 | Y90L-4 | 1.5 | 1131×1130×1492 |
| XB-1200 | 1200 | 1200 | 1.4 | 300 | 400 | 1.05 | Y132S-6 | 3 | 1500×1480×1800 |
| XB-1500 | 1500 | 1500 | 2.2 | 320 | 400 | 1.2 | Y132S-6 | 3 | 1750×1640×2190 |
| XB-2000 | 2000 | 2000 | 5.46 | 230 | 550 | 1.6 | Y132M2-6 | 5.5 | 2380×2162×2850 |
| XB-2500 | 2500 | 2500 | 11.2 | 230 | 650 | 3.44 | Y160L-6 | 11 | 3036×2716×3543 |
| XB-3000 | 3000 | 3000 | 19.1 | 210 | 700 | 4.61 | Y225S-8 | 18.5 | 3604×3216×4250 |
| XB-3500 | 3500 | 3500 | 30 | 230 | 850 | 7.28 | Y225M-8 | 22 | 3940×3766×5386 |
Any change of technical parameters, there is no further notice.
Latest Image of liquid mix agitators :
