30W ELN-30-24 MEANWELL/LED POWER SUPPLY/CE UL EMC

30W ELN-30-24 MEANWELL/LED POWER SUPPLY/CE UL EMC thumbnail-1
30W ELN-30-24 MEANWELL/LED POWER SUPPLY/CE UL EMC photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MEAN WELL
Model Number:
ELN-30-24
Contact Supplier Request Quote Chat Now
Hangzhou Gigamega New Energy Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name MEAN WELL
Model Number ELN-30-24
Output Type Single
Output Voltage 3-24VDC
Output Current 1.25A
Input Voltage Other, 90 ~ 264VAC 127 ~ 370VDC
Output Power Other, 30W

Specifications

30W ELN-30-24 MEAN WELL/Constant Current/
LED POWER SUPPLY
High quality/low price
UL CE EMC
2years warranty

MEANWELL LED POWER SUPPLY

ELN-30-24

MODEL

ELN-30-5

ELN-30-9

ELN-30-12

ELN-30-15

ELN-30-24

ELN-30-27

ELN-30-48

















OUTPUT

DC VOLTAGE

5V

9V

12V

15V

24V

27V

48V

CONSTANT CURRENT OPERATION VOLTAGE Note7

3 ~ 5V

3 ~ 9V

3 ~ 12V

3 ~ 15V

3 ~ 24V

3 ~ 27V

3 ~ 48V

RATED CURRENT

5A

3.4A

2.5A

2A

1.25A

1.12A

0.63A

CURRENT RANGE

0 ~ 5A

0 ~ 3.4A

0 ~ 2.5A

0 ~ 2A

0 ~ 1.25A

0 ~ 1.12A

0 ~ 0.63A

RATED POWER

25W

30.6W

30W

30W

30W

30.24W

  30.24W

RIPPLE & NOISE (max.)  Note.2

80mVp-p

100mVp-p

120mVp-p

120mVp-p

150mVp-p

150mVp-p

250mVp-p

VOLTAGE ADJ. RANGE

4.5 ~ 5.5V

8.7 ~ 10.5V

10.8 ~ 13.2V

13.5 ~ 16.5V

21.6 ~ 26.4V

24.3 ~ 29.7V

43.2 ~ 52.8V

Can be adjusted by internal potential meter SVR1

CURRENT ADJ. RANGE

-25% ~  3%. Can be adjusted by internal potential meter SVR2

VOLTAGE TOLERANCE   Note.3

5.0%

LINE REGULATION

1.0%

LOAD REGULATION

2.0%

SETUP TIME

500ms, 80ms / 230VAC 1000ms, 80ms / 115VAC at full load

HOLD UP TIME

50ms/230VAC  16ms/115VAC at full load









INPUT

VOLTAGE RANGE

90 ~ 264VAC 127 ~ 370VDC

FREQUENCY RANGE

47 ~ 63Hz

POWER FACTOR



EFFICIENCY (Typ.)

75%

80%

82%

82%

85%

85%

87%

AC CURRENT (Typ.)

0.75A/115VAC 0.48A/230VAC

INRUSH CURRENT (Typ.)

COLD START 60A/230VAC

LEAKAGE CURRENT

0.25mA / 240VAC



PROTECTION

OVER CURRENT

95 ~ 110%

Protection type : Constant current limiting, recovers automatically after fault condition is removed

SHORT CIRCUIT



OVER VOLTAGE

  5.75~6.75V

11 ~ 13.5V

13.8 ~ 16V

17.5 ~ 21V

28 ~ 32V

31 ~ 36.4V

54 ~ 60V

Protection type : Shut down o/p voltage, re-power on to recover

FUNCTION DIMMING CONTROL

1.1 ~ 10VDC .or PWM







ENVIRONMENT

WORKING TEMP.

-20 ~ +60oC (Refer to output load derating curve)

WORKING HUMIDITY

20 ~ 95% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +80oC , 10 ~ 95% RH

TEMP. COEFFICIENT

0.03%/oC (0 ~ 50oC )

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, period for  60min. each along X, Y, Z axes











SAFETY &EMC(Note 4)

SAFETY STANDARDS

UL1310 Class 2, CAN/CSA C22.2 No. 223-M91(except for 48V), IP64 approved ; design refer to TUV EN60950-1, EN61347-2-13



WITHSTAND VOLTAGE

I/P-O/P:3KVAC

ISOLATION RESISTANCE

I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH

EMI CONDUCTION & RADIATION

Compliance to EN55022 (CISPR22) Class B

HARMONIC CURRENT

Compliance to EN61000-3-2 Class A, EN61000-3-3

EMS

IMMUNITY

Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, light industry level,  criteria A



OTHERS

MTBF

628.3Khrs min. MIL-HDBK-217F

DIMENSION

145*47*30mm (L*W*H)

PACKING

0.26Kg; 60pcs/16.6Kg/1.25CUFT













NOTE

1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25oCof ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire region for LED related applications.

8. In the European market this power supply can be used for LED lighting applications with input power up to 25W.
