200w power for led
- 17000 Piece / Pieces per Month
- Shanghai
- Credit Card PayPal
- ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
- MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
- Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
- Power Supplies TVD1.3-15-03 Original Stock
- 10W 2.5KV Isolation Wide Input AC/DC Converters
- 30W Wide Voltage Input DC/DC Converters power supply
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | 200w power for led | Model Number: | LPH-18-12 |
Output Type: | Single | Output Voltage: | DC12V,24V,36V | ||
Output Current: | 0-1.5A | Input Voltage: | Other, 180 ~ 264VAC 254 ~ 370VDC |
Product Description
Specifications
200w power for led1, 100% Full Load Burn-in Test
2, TUV CE UL CB Rohs
3, +2years warranty
4, 27 years experience
200w power for led
we can supply complete series of LED power supply,1-600w,constant current,constant voltage,dimming,RGB controller and more.Welcome your inquiry!
MODEL | LPH-18-12 | LPH-18-24 | LPH-18-36 | |
OUTPUT | DC VOLTAGE | 12V | 24V | 36V |
CONSTANT CURRENT OPERATION VOLTAGE Note7 |
| |||
CURRENT RANGE | 0 ~ 1.5A | 0 ~ 0.75A | 0 ~ 0.5A | |
RATED CURRENT | 1.5A | 0.75A | 0.5A | |
RATED POWER | 18W | 18W | 18W | |
RIPPLE & NOISE (max.) Note.2 | 120mVp-p | 150mVp-p | 200mVp-p | |
VOLTAGE ADJ. RANGE |
| |||
CURRENT ADJ. RANGE |
| |||
VOLTAGE TOLERANCE Note.3 | 3.0% | |||
LINE REGULATION | 1.0% | |||
LOAD REGULATION | 2.0% | |||
SETUP, RISE TIME | 1500ms, 30ms / 230VAC | |||
HOLD UP TIME (Typ.) | 50ms/230VAC at full load | |||
INPUT | VOLTAGE RANGE | 180 ~ 264VAC 254 ~ 370VDC | ||
FREQUENCY RANGE | 47 ~ 63Hz | |||
POWER FACTOR |
| |||
EFFICIENCY (Typ.) | 78% | 82% | 83% | |
AC CURRENT (Typ.) | 0.3A/230VAC | |||
INRUSH CURRENT (Typ.) | Cold start 50A/230VAC | |||
LEAKAGE CURRENT | 0.25mA / 240VAC | |||
PROTECTION | OVER CURRENT | Above 105% rated output power | ||
Protection type : Hiccup mode, recovers automatically after fault condition is removed | ||||
SHORT CIRCUIT |
| |||
OVER VOLTAGE | 13.8~ 16.2V | 27.6~ 32.4V | 41.4 ~ 48.6V | |
Protection type : Shut off o/p voltage, clamping by zener diode | ||||
OVER TEMPERATURE | Tj 170 t ypically (U1) Detect on main control IC | |||
Protection type : Hiccup mode, recovers automatically after temperature goes down | ||||
ENVIRONMENT | WORKING TEMP. | -30 ~ +70 (Refer to output load derating curve) | ||
WORKING HUMIDITY | 20 ~ 90% RH non-condensing | |||
STORAGE TEMP., HUMIDITY | -40 ~ +80 , 10 ~ 95% RH | |||
TEMP. COEFFICIENT | 0.03%/ (0 ~ 50 ) | |||
VIBRATION | 10 ~ 500Hz, 2G 12min./1cycle, period for 60min. each along X, Y, Z axes | |||
SAFETY &EMC(Note 4) | SAFETY STANDARDS | |||
WITHSTAND VOLTAGE | I/P-O/P:3KVAC | |||
ISOLATION RESISTANCE | I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH | |||
EMI CONDUCTION & RADIATION | Compliance to EN55022 (CISPR22) Class B | |||
HARMONIC CURRENT | Compliance to EN61000-3-2 Class A, EN61000-3-3 | |||
EMS IMMUNITY | ||||
OTHERS | MTBF | 1200.6K hrs min. MIL-HDBK-217F (25 ) | ||
DIMENSION | 140*30*22(L*W*H) | |||
PACKING | 0.175Kg; 70pcs/13.3Kgs/0.71CUFT | |||
NOTE |
|
we can supply complete series of LED power supply,1-600w,constant current,constant voltage,dimming,RGB controller and more.Welcome your inquiry!
