U shape pallet scales PU movable platform weighing scale Supplier's Choice
- 10000 Set / Sets per Month
- shanghai
- T/T D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | silvanus | Model Number: | PU |
Type: | Truck Scale | Power Supply: | AC | Display Type: | LED |
Rated Load: | 3t | Accuracy: | 1kg |
Product Description
U shape pallet platform weighing scale
U shape platform weighing scale Introduction:
SCS series, PU electronic platform scale is designed for carrying goods in transporting cars, trucks or forklift trucks. easy to move and carry, weighing is flexible and stable, applicable widely applicable
(1)u-type steel structure, with 4pcs XBC load cell, four wire junction box 1pc, 1 pc single shielded signal cable 5 m, A12 indicator 1pc;
(2)PUS scale material: Carbon steel;
(3)carton packaging;
Structure features | technology |
u type structure: easy to move goods for car, and forklift | accuracy grade: OIML III |
with put hand and wheel: handling convenient | weight range:0.5t~3t |
signal cable ends with plug: connection simple | Safe overload:125%F.S |
weight is light: easy tomaintenance | load cell work temperature:-30℃~+70℃ |
Wiring box install data in drawer type | Indicator work temperature:-10℃~+40℃ |
Number display weighing date | Power supply voltage:220VAC/50Hz |
U shape platform weighing scale specification:
Model | Size(mm) | Max Capacity(t) | Division(kg) | Remark |
SCS-PU-1.5t | 840×1250×80 | 1.5 | 0.5/1 | Carbon Steel |
SCS-PU-3t | 840×1250×80 | 3 | 1 | Carbon Steel |
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
LETTER OF PATENT:
Transportation | Routine |
By car | 3 hours from Shanghai to Yixing |
By high speed railway | 2 hour from Shanghai(or Shanghai Hongqiao) railway station to YiXing railway station,then we will pick you up.It will take 10 mins by car from Yixing railway station to our company. |
