PCS Stainless Steel Itra-low table weighing electronic platform scales
Introduction:
SCS series, PCS electronic platform scale is ltra-low table weighing electronic platform scales. It designed for handling car, rounded barrel storage/box , slope of scales is separate design.
Scale material: Stainless steel structural, equipped with XBH load cell, scale body consists of 1pc four line junction box , 1pc single break, 1 pc 5-meter signal cable, an T8 instrument ;
The Platform scale is equipped with weighing systems, which compose of high precision weighing sensor and intelligent AC DC weighing instruments. The system is high accurately, weighing rapid, stable and reliable, simple to install and maintain, easy to carry. Widely used in commercial warehouses and distribution centers; postal distribution centers; railways, highways, aviation and cargo shipment business weighing; pharmaceuticals, food manufacturing companies weighing of finished and semi-finished products. Install additional assistive devices on the platform to suit user extended application needs.
Structure features |
technology |
Stainless steel structural, |
accuracy grade: OIML III |
With automatic reset transfer mechanism |
weight range:500kg~5t |
Ultra low table: 35mm~45mm |
Safe overload:125%F.S |
Ultra short :300mm |
load cell work temperature:-30℃~+70℃ |
A limit of forming, no need to adjust |
Indicator work temperature:-10℃~+40℃ |
Drawer-type waterproof flush junction box installation |
Power supply voltage:220VAC/50Hz |
Specification:
Model |
Max Capacity(t) |
Size (W×L) (m) |
Division (kg) |
Height (mm) |
PCS0.3-0808 |
300 |
0.8×0.8 |
0.2 |
35mm~45mm |
PCS0.6-0808 |
600 |
0.8×0.8 |
0.2/0.5 |
35mm~45mm |
PCS1-0808 |
1000 |
0.8×0.8 |
1 |
35mm~45mm |
PCS0.3-1010 |
300 |
1.0×1.0 |
0.2 |
35mm~45mm |
PCS0.6-1010 |
600 |
1.0×1.0 |
0.2/0.5 |
35mm~45mm |
PCS1-1010 |
1000 |
1.0×1.0 |
1 |
35mm~45mm |
PCS1.5-1010 |
1500 |
1.0×1.0 |
1 |
35mm~45mm |
PCS0.3-1212 |
300 |
1.2×1.2 |
0.2 |
35mm~45mm |
PCS0.6-1212 |
600 |
1.2×1.2 |
0.2/0.5 |
35mm~45mm |
PCS1-1212 |
1000 |
1.2×1.2 |
0.5 |
35mm~45mm |
PCS1.5-1212 |
1500 |
1.2×1.2 |
0.5 |
35mm~45mm |
PCS1-1215 |
1000 |
1.2×1.5 |
0.5 |
35mm~45mm |
PCS3-1215 |
3000 |
1.2×1.5 |
1 |
35mm~45mm |
PCS1-1515 |
1000 |
1.5×1.5 |
0.5 |
35mm~45mm |
PCS3-1515 |
3000 |
1.5×1.5 |
1 |
35mm~45mm |
The specifications of table and max capacity can be customized according to customers requirements | ||||
Packaging & Delivery
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
