PKF stainless electronic platform scale with frame
Introduction:
SCS series, PKF electronic platform scale is made of stainless steel welding scale, Platform scale structure formed by the scale body and frame. Stainless steel material is 0Cr18Ni9, equipped with four high-precision hermetically welded stainless steel weighing laod cell and intelligent weighing indicator. The system is high accuracy, weighing speedy, stable and reliable, simple and convenient to install and maintain. Mainly used in high requirement environment or slightly corrosive environments, such as chemical industry, pharmaceuticals, food, paint industry. suitable for lifting goods weighing, forklift backhoe good weighing , cars carrying goods weighing. Can weigh on retrofitted auxiliary devices to accommodate the user extended application needs. Customer can choose ramps and framework (both stainless steel and carbon steel), indicator column
Structure feature |
Technique Index |
stainless steel plate and load cell |
Precision Class : OIML III |
Ultra low floor structure |
Rated Load:1t~10t |
The platform composed of scale body and frame |
Safe Load Limit:125%F.S |
Automatic replacement structures |
Working Temperature of Load Cell :-30℃~+70℃ |
No need to adjust the limit |
Working Temperature of Indicator :-10℃~+40℃ |
Epoxy baking of the surface |
Power Supply :110~220AVC , 50~60Hz |
Specification:
Model |
Max capacity (t) |
Platfrom Size (W×L) (m) |
Division (kg) |
Height (mm) |
SCS-PKF-0.5/1/2t-0808 |
0.5/1/2 |
0.8×0.8 |
0.2/0.5/1 |
90 |
SCS-PKF-1/2/3t-1010 |
1/2/3 |
1.0×1.0 |
0.5/1/1 |
90 |
SCS-PKF-1/2/3t-1012 |
1/2/3 |
1.0×1.2 |
0.5/1/1 |
90 |
SCS-PKF-1/2/3t-1212 |
1/2/3 |
1.2×1.2 |
0.5/1/1 |
90 |
SCS-PKF-1/2/3t-1215 |
1/2/3 |
1.2×1.5 |
0.5/1/1 |
90 |
SCS-PKF-1/2/3t-1515 |
1/2/3 |
1.5×1.5 |
0.5/1/1 |
90 |
SCS-PKF-5t-1515 |
5 |
1.5×1.5 |
2 |
90 |
SCS-PKF-1/2/3t-1520 |
1/2/3 |
1.5×2.0 |
0.5/1/1 |
90 |
SCS-PKF-5t-1520 |
5 |
1.5×2.0 |
2 |
90 |
SCS-PKF-1/2/3t-2020 |
1/2/3 |
2.0×2.0 |
0.5/1/1 |
90 |
SCS-PKF-5t-2020 |
5 |
2.0×2.0 |
2 |
90 |
The specifications of plate and max capacity can be customized according to customers requirements | ||||
Packaging & Delivery
Delivery Usually 15days after receiving 30% deposit (for T/T terms), but 30days for customized.
Our Company:
Silvanus Electric Manufacture (Yixing) Co., Ltd. is a professional hi-tech enterprise, which specializes in manufacturing high precision load cells.
On the basis of strong R&D ability and advanced equipment in production, inspection and testing, we specialize in scientific research, production and sales of all kinds of high precision load cells. Our products are widely used in electric weighing apparatuses, metallurgy, petrifaction, environmental protection, mechanism, textiles, medicines, construction examining, and ports.
We insist on the policy of "customer oriented" and aim at producing the best load cells. In controlling and managing the quality of our products. We comply with OIML and ISO9001:2000 standards. According to the quality policy of "Through building a system of quality and management which is lasting and effective", we serve customers with better quality products on time. We will always improve ourselves and bring our company a brand-new future.
LETTER OF PATENT:
Transportation |
Routine |
| By car | 3 hours from Shanghai to Yixing |
| By high speed railway | 2 hour from Shanghai(or Shanghai Hongqiao) railway station to YiXing railway station,then we will pick you up.It will take 10 mins by car from Yixing railway station to our company. |
