Home > Security & Protection > Fire Control > Other Fire Control Equipment > Blocking Relay

Blocking Relay

Name: Blocking Relay
Brand: ARTON
SKU: 110191523

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Ukraine

Brand Name:

ARTON

Model Number:

BR4-4

Contact Supplier Request Quote Chat Now

Arton Private Enterprise

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Ukraine

Brand Name ARTON

Model Number BR4-4

Specifications

The relay expands functions of ARTON fire alarm control panels.

BR4-4 blocking relays are designed to expand functions of ARTON fire alarm control panels. BR can be used to transmit signals to CMS, control of alarm signals and provide galvanic uncoupling of FACP output signals.

Blocking relays consist of corresponding number of NC/NO relays.

TECHNICAL SPECIFICATIONS

Parameters	Blocking relay
Parameters	BR4-4
Arton-04F	•
Arton-08F	•
Arton-16F
Arton-32F
Relay winding voltage	9-13,8 V
Number of relays	4
Max commutable voltage	36 V
Max commutable current	0,5 A
Time of relay contacts triggering	3 ms
Time of relay contacts releasing	2 ms
Dimensions	50x60x20 mm
Weight	200 g

The BR is fitted on the corresponding PCB of “ARTON-xxF” FACP using board-to-board connectors supplied with the blocking relay.

The BR4-4 is connected to ARTON-04F, ARTON-08F by connecting BR4-4 to main control PCB of the control panel using a flexible loop of BR. While inputs “In1”-“In4” of BR can be connected to the appropriate BR key, and inputs ”_↓” to any terminal ”↓” of BK.

Functioning of each relay is defined by activity of the BK output connected to its input and the position of the corresponding switch (NO, NC).
