Dahua video intercom Apartment Outdoor Station VTO1220BW
Features:
>3.5-inch TFT screen, vivid pictures are on show
>Tempered glass panel, touch buttons.
>Adopt TCP/IP network host, support SNMP network protocol.
>Network security technology, provides stable and safe operating environment.
>Support night vision, voice indication
>Support card and password to open the door
>Support visitor leaving audio and video function message
>IP65
Specification:
| Mode | DH-VTO1220BW | |
| System | Main Processor | Embedded micro processor |
| Operation System | Embedded LINUX OS | |
| Video | Video Compression Standard | H.264 |
| Input/Approaching Induction | 1.3 megapixel CMOS camera | |
| Black Light | Support | |
| Auto Light Compensation | Support | |
| Audio | Audio Input | Microphone |
| Audio Output | Built-in speaker | |
| Bidirectional Talk | Support dual-way bidirectional talk | |
| Display | LCD Dimensions | 3.5-inch TFT screen |
| Resolution | 320*240 | |
| Operation Mode | Input | Touch keyboard |
| Card | Built-in IC card induction reader | |
| Approaching Induction | Body Approaching | IR,1 meter |
| Alarm | Vandal proof | Support |
| Access Control | No Output | Support |
| NC Output | Support | |
| Door on/off Button | Support | |
| Door Status Detect | Support | |
| Network | Ethernet | 10M/100Mbps Self-adaptive |
| Network Protocol | TCP/IP | |
| Storage | Memory | 128MB |
| Others | Power | DC 10~15V |
| Power Consumption | Standby ≤1W,work ≤10W | |
| Working Environments | -40℃-+60℃ | |
| 10%-95%RH | ||
| Water Proof | IP65 | |
| Dimensions | 408.0mm*150.0mm*46.4mm(L*W*T); | |
| Weight | 1.6Kg; | |
| Installation Method | Flush mounted | |
