walk in oven factory
application:
walk in oven is available for quality inspection for all types of big test samples, such as electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries
walk in oven factory / features :
1. Graceful appearance, circularly shaped body, surface treated with mist strips and plane handle with no reaction. Easy to operate, safe and reliable.
2. Rectangular viewing window for the observation of products under test, equipped with sweat-proof electrical heating device that can prevent water steam from condensing into droplets, and interior lights
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. French Tecumseh is used for circulation system
6. LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, and of quick temperature ramp velocity control
8. Casters are provided for ease of mobility, with strong positioning screws.
walk in oven / technical parameters:
Model |
THR-volume (low-temperature options : A ~ F) |
Inner Dimensions(cm) |
Customers designated space size and design |
Temperature Range |
Low Temperature(A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) High Temperature 80°C (80°C ~150°C is optional) |
Humidity Range |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is a optional , need dehumidifier) |
Indication Resolution / Distribution Uniformity of Temperature and Humidity |
0.1°C; 0.1% R.H/±2.5°C; ±3.5% R.H. |
Control Accuracy of Temperature and Humidity |
±0.5°C; ±2.5% R.H. |
Temperature Rising / Falling Velocity |
Rising velocity approx. 0.1~3.0°C/min; falling velocity approx. 0.1~1.0°C/min;( The Falling velocity >1.0°C /min is optional) |
Cooling System |
Water cooled |
Protection Devices |
Fuse-free switch, overloading protection switch for compressor,high and low voltage coolant protection switch, over-humidity & over-temperature protection switch, fuses,fault warning system, water short storage warning protection |
Optional Accessories |
Slope for cart , Recorder, Water Purifier, Dehumidifier |
Compressor |
French Tecumseh , Germany Bizer |
Power |
AC 380 V 50/60HZ |
More walk in oven factory pictures :
