Help Center4Channel H.264 Network Video Server
Related Products
Specifications
4 channel H.264 Network video serverFull channel@D1 realtime encording
Video output: 1TV, 1Spot BNC,
SD, Max 32GB
Features:
> 1/2/4 channel video and audio inputs
> H.264 video compression and JPEG image capture
> Full channel@D1(4CIF) realtime encording
> 3D intelligent positioning with PTZ dome camera
> 3G (Model –E/-C only), Wi-Fi (Model –W only), SD memory
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Model |
KDW-DS601DX |
KDW-DS602DX |
KDW-DS604DX |
||||
System | |||||||
Main Processor |
Dual-core embedded processor |
||||||
Operating System |
Embedded LINUX |
||||||
Video | |||||||
Input |
1 channel |
2 channel |
4 channel |
||||
Output |
1 TV output, BNC |
||||||
Standards |
PAL(625Line, 50f/s), NTSC |
||||||
Audio | |||||||
Input |
1 channel |
2 channel |
4 channel |
||||
Output |
1 channel |
||||||
Two-way Talk |
1 channel Input, 1 channel Output |
||||||
Display | |||||||
Resolution |
1280×1024, 1280×720, 1024×768, 800×600 |
||||||
Display Split |
1 |
1/4 |
1/4 |
||||
Privacy Masking |
4 rectangular zones (each camera) |
||||||
Recording | |||||||
Video/Audio Compression |
H.264 / G.711 |
||||||
Resolution |
D1/CIF/QCIF/VGA/QVGA |
||||||
Record |
Mainstream |
D1/BCIF/CIF/QCIF(1~25/30fps) |
|||||
Extra stream |
D1/BCIF/CIF/QCIF |
||||||
Digital Watermark |
Support |
||||||
Video Detection & Alarm | |||||||
Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips |
||||||
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
||||||
Alarm Input |
4 channel |
||||||
Relay Output |
2 channel |
||||||
Playback & Backup | |||||||
Search Mode |
Time/Date, Alarm, Motion Detection & Exact search (accurate to second) |
||||||
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
||||||
Storage | |||||||
Memory Slot |
SD, Max 32GB |
||||||
Backup Mode |
Network |
||||||
Network | |||||||
Ethernet |
RJ-45 (10/100Base-T) |
||||||
Wireless |
3G |
EVDO(CDMA1X)/WCDMA and other 3G network (model–E/-C only) |
|||||
Wi-Fi |
802.11bg (model –W only) |
||||||
Network Functions |
TCP/IP, PPPOE,DDNS, FTP, IP Filter, DNS, SMTP, NTP, DHCP |
||||||
Auxiliary Interface | |||||||
USB |
1 Port |
||||||
RS485 |
PTZ control |
||||||
General | |||||||
Power Supply |
DC12V / 3A |
||||||
Power Consumption |
<5W |
||||||
Working Environment |
-30°C ~+50°C / 10%~90% / 86kpa~106kpa |
||||||
Dimension(W×D×H) |
162mm ×136mm × 30mm |
||||||
Weight |
1.0Kg |
||||||
