Machine for three axis electrodynamic vibration test
technical parameters:
Model |
Rated Sine Force (N) |
Rated Random Force (N) |
Frequency Range (Hz) |
Rated Acceleration (m/s2) |
Rated Speed (m/s) |
Rated Displacement (p-p)mm |
Max. Loading (Kg) |
moving coil (Kg) |
Dimension of Moving coil (mm) |
ES-1 |
1000 |
1000 |
3-3500 |
400 |
1.2 |
25 |
70 |
2.5 |
Φ150 |
ES-2 |
2000 |
2000 |
3-3500 |
800 |
1.6 |
25 |
70 |
2.5 |
Φ150 |
ES-2a |
2000 |
2000 |
3-3500 |
300 |
1.6 |
40 |
70 |
8 |
Φ230 |
ES-3 |
3000 |
3000 |
3-3500 |
1000 |
1.6 |
25 |
100 |
3.5 |
Φ150 |
ES-3a |
3000 |
3000 |
3-3500 |
400 |
1.6 |
40 |
120 |
9 |
Φ230 |
..... | |||||||||
ES-160 |
160000 |
160000 |
3-2100 |
1000 |
1.8 |
51 |
1500 |
150 |
Φ600 |
ES-200 |
200000 |
200000 |
3-2000 |
1000 |
1.8 |
51 |
2500 |
200 |
Φ650 |
ES-350 |
350000 |
350000 |
3-1700 |
1000 |
1.8 |
51 |
4500 |
300 |
Φ870 |
Machine for three axis electrodynamic vibration test technical parameters of horizontal bench:
Model |
Bench Size (mm) |
Frequency Range (Hz) |
Weight of Moving Parts (kg) |
LT0303 |
300×300×22 |
5-1000 |
6.6 |
.... | |||
LT 1212 |
1200× 1200×30 |
5-800 |
126 |
Machine for three axis electrodynamic vibration test technical parameters of vertical bench:
Model |
Weight (kg) |
Max. Frequency (Hz) |
Bench Size (mm) |
VT300 |
10 |
2000 |
Φ300 |
VT400 |
16 |
2000 |
Φ400 |
.... | |||
VT1212 (Round bench) |
220 |
350 |
Φ1200 |
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
Warranty: one year free warranty for whole set machine,lifelong time maintainance.
Service:OEM service,Design service,Buyer lable service.
After-sale service: feedback within 2 hours after get the call.
Short introduction about ASLi factory:
We are a long history testing equipment manufacturer, in the past 25 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. Machine for three axis electrodynamic vibration test is our star products, and we had obtained the CE certification for this machine.
