High Frequency Vibration Test Chamber
ASLI, as a leading high frequency vibration test chamber supplier from China, has more than 25 year’s experience in high frequency vibration test chamber manufacture. ASLI boost his own technical team in high frequency vibration test chamber R&D, and it also introduces the advance quality control method in high frequency vibration test chamber production. Our high frequency vibration test chamber series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
High Frequency Vibration Test Chamber Application :
High frequency vibration test chamber widely used in inspection, manufacturing ,production and laboratory. Measurements of the vibration test system provide the following parameters: vibration acceleration, vibration velocity and vibration displacement. In this way the vibration is recorded with great precision. The vibration testing equipment is a portable device and its readings can be stored and retrieved for later use. The manufacturer's calibration certificates are included with your vibration tester. Additionally, the vibration measurement can come accompanied with ISO 9000 certification, either with the first order or with its annual recalibration as stated in the ISO manual. The vibration meter is an irreplaceable tool for the professional on the job. Every vibration meter can carry out the demanding task regardless of the technical problem to hand.
High Frequency Vibration Test Chamber Features:
1.Asli brand high frequency vibration test chamber with well-designed dynamic circle skeleton, with a higher stage axial resonance frequency.
2. Asli brand high frequency vibration test chamber with two-magnetic circuit, magnetic flux leakage low, compact structure and rational.
3. Asli brand high frequency vibration test chamber with rocker rod roller bearings straight and import-oriented composite body stiffness orientation, eccentric load capacity.
4. Asli brand high frequency vibration test chamber with runnion isolation foundation dedicated to hormone use, the installation of mobile convenience.
5. Asli brand high frequency vibration test chamber with advanced technology move around the system to ensure that the dynamic circle of high reliability.
6. Asli brand high frequency vibration test chamber with new duct design and enhance the cooling effect.
7. Asli brand high frequency vibration test chamber with static stiffness, dynamic stiffness of the bearing small balloon, raising the vibration table bearing capacity.
High Frequency Vibration Test Chamber Technical Parameters :
Model |
Rated Sine Force (N) |
Rated Random Force (N) |
Frequency Range (Hz) |
Rated Acceleration (m/s2) |
Rated Speed (m/s) |
Rated Replacement (p-p)mm |
Max. Loading (Kg) |
Moving Coil(Kg) |
Dimension of Moving coil (mm) |
ES-1 |
1000 |
1000 |
3-3500 |
400 |
1.2 |
25 |
70 |
2.5 |
Φ150 |
ES-2 |
2000 |
2000 |
3-3500 |
800 |
1.6 |
25 |
70 |
2.5 |
Φ150 |
ES-2a |
2000 |
2000 |
3-3500 |
300 |
1.6 |
40 |
70 |
8 |
Φ230 |
ES-3 |
3000 |
3000 |
3-3500 |
1000 |
1.6 |
25 |
100 |
3.5 |
Φ150 |
ES-3a |
3000 |
3000 |
3-3500 |
400 |
1.6 |
40 |
120 |
9 |
Φ230 |
ES-6 |
6000 |
6000 |
3-3500 |
1000 |
1.6 |
25 |
180 |
6.5 |
Φ230 |
ES-6a |
6000 |
6000 |
3-3500 |
1000 |
1.6 |
51 |
250 |
12 |
Φ230 |
ES-10 |
10000 |
10000 |
3-3000 |
1000 |
1.8 |
51 |
270 |
14 |
Φ240 |
ES-20 |
20000 |
20000 |
3-3000 |
1000 |
1.8 |
51 |
300 |
30 |
Φ320 |
...
