GWSECU H.264 NVR(POE)
Features:
>H.264/MJPEG-4 dual codec decoding;
>VGA/HDMI video simultaneous output;
>All channel synchronous real time preview;
>ONVIF Version 2.4,downward compatibility;
>Support 1 SATA HDD up to 6TB, 2 USB2.0;
>Support 10M/100M NIC;
>P2P Cloud Monitoring;
>Multiple language built-in;
>Support network camera a button to add functionality.
Specification:
Model |
KD-Z3404NE-P |
|
Special function | ||
P2P function |
Using Device ID and password to login ; Realize remote monitoring playback and control like IE Web login. No need any network IP setting easy for end user to use network function. |
|
System | ||
Operation System |
embedded LINUX |
|
Pentaplex function |
Live monitoring recording playback backup & remote access |
|
Control Mode |
USB mouseNetwork Remote |
|
Video &Audio | ||
IP Camera Input |
4ch.(48Mbps) |
|
Incoming Bandwidth |
48Mbps |
|
Outgoing bandwidth |
48Mbps |
|
Support Protocol |
Support Protocol ONVIF |
|
Standard |
PAL / NTSC |
|
Output |
1 HDMI 1 VGA 1CVBS BNC(1.0Vp-p75ohms) 4MP/3MP/1920×1080 1280×1024 1280×720 1024×768 |
|
Image Display | ||
Resolution |
4MP/3MP/1920×10801280×720 |
|
Privacy Masking |
Four zones for privacy masking for each channel |
|
Recording | ||
| Video Compression | H.264 | |
Resolution |
Main stream: 1920*2048P max. Auxiliary stream: D1 max. |
|
Image Encoding |
Adjustable encoding quality variable code stream/fixed code stream |
|
Dual Stream |
Support |
|
Time bar |
Support |
|
Recording Mode |
Manual auto motion detection stop |
|
Video Detection | ||
Trigger Events |
Recording PTZ TourEmail |
|
Motion Detection |
396 (22×18) detection zone variable sensitivity levels |
|
Capture |
JPEG capture |
|
Playback&Backup | ||
Max Playback |
1/2/4 ch. |
|
Backup Mode |
USB,HDD,Network Backup |
|
Network | ||
Ethernet |
1 RJ-45 port (10M/100M) |
|
Network protocol |
TCP/IP UDP HTTP RTP/RTSP |
|
Network Functions |
DHCP PPPOE DDNSSMTPSNTPFTPUPnPP2P |
|
Remote Operation |
Monitoringplaybacksystem settingfile downloadlog information |
|
Smart Phone |
iPhone,iPad,Android |
|
Hard Disk | ||
Hard Disk |
1 SATA porteach SATA supports 4TB |
|
HDD Management |
Hard disk hibernation technology HDD faulty alarm & raid |
|
Auxiliary Interface | ||
USB |
2 USB 2.0 ports |
|
General | ||
POE function |
4 ch. |
|
IEEE 802.3af | ||
DC48V/1.35A(POE) | ||
RJ45 10M/100M | ||
Output power |
≤45W |
|
Power Supply |
DC 48V 1.35A |
|
Power Consumption |
5W (without HDDPOE) |
|
Working Environment |
-10℃~+55℃ / 10%-90%RH |
|
Dimension(L*W*H) |
235x215x45 (mm) |
|
Weight |
0.9Kg (without HDD) |
|
Installation |
Desk type |
|
CMS&VSS Interface:
Web Interface:
Mobile Phone View:
1. Onvif 2.42, High compatibility, Dahua,Hikivison, Nuuo, Axxon, Milestone, Geovision, Avigilon, Luxriot, See Tec, Aimetis, Genetec
2. GWSECU Strong mental housing; Same housing with different function of different system. H.265/H.264 1.3/2.0/3.0/4.0/5.0 Megapixel IP camera with Motorized lens/ Ultra WDR /low lux/ low stream,HD AHD,CVI,TVI for your choice.
3.GWSECU Perfect structure -heat disspating from bracket, Easy to put SD Card
4. Latest ARRAY LED--- work more longer life.
5.Support Multi-language, P2P and two-dimension Code.
6.User-friendly Web interface and CMS design, convinient for clients to use.
7.High quality control and full OEM Service (put your logo on camera and software, gift box, language.etc)
8.Fast shipping time(500pcs within 15 days).
9. Two year warranty and FREE online technical help with our engineer after sale.
Shenzhen Guowei Security Co., ltd.
Headquarters:
Add.: 6/F, Dong Fang Building 1, No.16 Gaoxin North 6th Road,North High-tech Industrial Park, Nanshan District, Shenzhen, China (518108)
Our Factory
Add.: 4/F, Jinma Building, Shihuan Rd, Shilongzai Community, Shiyan, Baoan District, Shenzhen, China
Zip Code: 518108
Branch:Hongkong Guowei Security co.,limited
Add.: Rm.602,Metro Center I,Lam Hing Street Kowloon Bay.N.T.
We provide 2 years warranty service for all products.
OEM service: Silk-print with brand, IE Browser Login, WEB GUI page, local CMS software with customize brand.
1. Payment
What are the terms of payments you offer?
We accept payment via T/T, Paypal, Westunion,L/C at sight or Alipay via Alibaba
2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 7-10 working days after an order confirmed
3. What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.
4. What kind of transportation methods you offer?
A. We usually choose the cheapest express delivery for our clients, such as DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.You could use your own forwarder if possible.
B. We also can deliver your goods by air and sea as your request.
