Help CenterGwsecu 2016 DAHUA 16CH 1U 4K&H.265 ONVIF NVR DHNVR5216-4KS2
Related Products
-
Gwsecu 2016 H.264 DAHUA 8CH Mini 1U 4PoE NVR1108H-PUS$ 73 - 94MOQ: 1 Piece -
Gwsecu 2016 Cheap Price H.264 5Mp Resolution DAHUA 8CH Smart 1U NVR4108US$ 61 - 69MOQ: 1 Piece
-
Gwsecu 2016 DAHUA 16CH 2U 4K H.265/H.264/codec Decoding NVR5816-4KS2 POEUS$ 346 - 401MOQ: 1 Piece
-
Gwsecu 2016 DAHUA 32CH 2U 4K H.265/H.264/ Codec Decoding NVR5832-4KS2 16POEUS$ 399 - 438MOQ: 1 Piece
-
Gwsecu Cheap Price H.264 DAHUA 8CH Smart Box NVR104US$ 42 - 55MOQ: 1 Piece
GWSECU is Dahua authorized company to sell their products to oversea.And we do it for many years.
We supply dahua ip camera, dahua nvr, dahua hdcvi camera/dvr,dahua dvr
Please add +86- 188 7414 0007 to your phone contact & whatsapp
>Up to 8/16/32 channel IPC input
>H.265/H.264/MJPEG/MPEG4 codec decoding
>Max 320Mbps incoming bandwidth
>Up to 12Mp resolution preview&playback
>Max 16ch@1080P H.265/H.264 decoding
>HDMI/VGA simultaneous video output
>4/8/16 channel synchronous realtime playback, GRID interface
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.
>ONVIF Version 2.4 conformance
>3D intelligent positioning with Dahua PTZ camera
>Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)
>Support IPC UPnP, 8PoE ports for PoE model
>Multiple network monitoring: Web, CMS(DSS/Smart PSS) & Mobile phone (DMSS)
We company integrates the design,development,production and sales of network video surveiillance products in Shenzhen nearly ten years.
GWSECU office building and factory
on fair
Our products based on the high quality, quality testing superior.
Specifications
| Model | DH-NVR5208-4KS2 DH-NVR5208-8P-4KS2 | DH-NVR5216-4KS2 DH-NVR5216-8P-4KS2 | DH-NVR5232-4KS2 DH-NVR5232-8P-4KS2 |
| System | |||
| Main Processor | Quad-core embedded processor | ||
| Operating System | Embedded LINUX | ||
| Video& Audio | |||
| IP Camera Input | 8 channel | 16 channel | 32 channel |
| Two-way Talk | 1 channel Input, 1 channel Output, RCA | ||
| Display | |||
| Interface | 1 HDMI (up to 3840x2160), 1 VGA | ||
| Resolution | 3840x2160, 1920×1080, 1280×1024, 1280×720, 1024×768 | ||
| Display Split | 1/4/8/9 | 1/4/8/9/16 | 1/4/8/9/16/25/36 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | ||
| Recording | |||
| Compression | H.265/H.264/MJPEG/MPEG4 | ||
| Resolution | 12Mp/8Mp/6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc. | ||
| Record Rate | 320Mbps | ||
| Bit Rate | 16kbps~ 20Mbps for per channel | ||
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop | ||
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | ||
| Video Detection & Alarm | |||
| Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips | ||
| Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank | ||
| Alarm Input | 4 channel | ||
| Relay Output | 2 channel | ||
| Playback & Backup | |||
| Sync Playback | 1/4/8 | 1/4/8/16 | 1/4/8/16 |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | ||
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | ||
| Backup Mode | USB Device/Network/Internal SATA burner | ||
| Network | |||
| Ethernet | 1 RJ-45 port (10/100/1000Mbps) | ||
| PoE | 8 ports (IEEE802.3af/at) for PoE model | ||
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P | ||
| Max. User Access | 128 users | ||
| Smart Phone | iPhone, iPad, Android | ||
| Storage | |||
| Internal HDD | 2 SATA ports, up to 12TB | ||
| Auxiliary Interface | |||
| USB | 2 ports (1 Rear USB3.0,1 Front USB2.0) | ||
| RS232 | 1 port, For PC communication&Keyboard | ||
| General | |||
| Power Supply | Single, DC12V/4A for non-PoE model Single, AC 100~240V, 50/60 Hz for PoE model | ||
| Power Consumption | NVR: 9.5 W for non-PoE model(without HDD) 15.2W for PoE model(without HDD) | ||
| PoE: Max 25.5W for single port, 130W in total | |||
| Working Environment | -10°C~+55°C / 10%~90%RH / 86~106kpa | ||
| Dimension (W×D×H) | 1U, 375mm×282mm×56mm(non-PoE model) 375mm×327mm×53mm(PoE model) | ||
| Weight | 1.6KG for non-PoE model(without HDD) 2.6KG for PoE model(without HDD) | ||
