UV Accelerated Weathering Test Chamber
ASLI , as a leading UV chamber supplier from China, has more than 25 year’s experience in UV chamber manufacture. ASLI boost his own technical team in UV chamber R&D, and it also introduces the advance quality control method in UV chamber production. Our UV chamber series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
UV Accelerated Weathering Test chamber Technical Parameters :
Model |
EC-A |
SC-A |
EC-B |
EC-C |
|||
Light Device |
UV carbon arc light |
Sunlight carbon arc light |
UV carbon arc light |
||||
Internal Dimension W×H×D (mm) |
1000×9000×1000 |
1100× 1000× 1100 |
700×900×700 |
||||
External Dimension W×H×D (mm) |
1300× 1300×2000 |
1300× 1300×2000 |
1150× 1800×900 |
||||
Testing Time (H.) |
20 |
60 |
20 |
||||
Testing Voltage |
120V~145V(135V) |
48V~52V(50V) |
120V~145V |
||||
Testing Current |
15A~17A(16A) |
58A~62A(60A) |
15A~17A |
||||
Black Ball Thermometer |
63±3°C~83±3°C |
||||||
Dia. Of Test Shelf (Φ, mm) |
800 |
960 |
508 |
||||
Revolution Speed of Testing Shelf (RPM) |
1 |
3 |
|||||
Sample Shelf |
390×70mm, 30 pcs |
390×70mm, 30 pcs |
248×50mm, 20 pcs |
||||
Temperature Range |
RT +10°C~85°C |
RT +10°C~63°C |
|||||
Humidity Range |
AT40°C ,RH is 40%~85% / AT80°C, RHis30%-50% |
Under 50%RH |
30%~85%RH |
||||
Carbon Rod |
Upper |
13Φ×305mm, 2 pcs |
35Φ×350mm,4pcs |
13Φ×305mm ,1pc, |
|||
Lower |
3Φ×100mm,4pcs |
23Φ×350mm,4pcs |
13Φ×100mm,2pcs |
||||
Power |
AC220V 1&3 lines |
AC380V 3& 5 lines |
AC220V 1& 3 lines |
||||
UV Accelerated Weathering Test Chamber Features:
1.Can record the temperature, humidity, arc light voltage, arc light current, BT black ball temperature and arc light in the same time.
2.60H continuous testing.
3.BT black ball temperature digital display, damper regulator can be controlled for stable of black ball's temperature.
4.Unique DEW design
5.All data use digital display for long time management.
6.Adopt carbon arc Intensity detector, to keep the wave length in standard range.
UV Accelerated Weathering Test Chamber Applications:
UV chamber is applied to test the sample aging resistant performance by explore the samples under simulated extremes sunlight ,humidity , etc. nature environmental conditions, can know the samples fade, transmittance, glossiness, stripping, hard, softening performance in short time. This machine is widely used in t he aviation industry, paint industry, coating industry. The automotive industry, textile industry, dye industry, plastic industry, building industry, etc.
More Detailed information about UV Chamber ,please do not hesitate to contact Asli sales !
Factory Pictures for your reference:
...
