Home > Products > UV/Xenon test chamber > Xenon Accelerated Tester
Xenon Accelerated Tester
- 30 Set / Sets per Month
- SHENZHEN/ HONGKONG
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Place of Origin | Guangdong, China | Brand Name | ASLi | |
Model Number | XL Seires | Power | Other, Electronic, AC 380V | |
Usage | Universal Testing Machine |
Product Description
Xenon Accelerated Tester application:
Xenon Accelerate Tester is used to do climatic aging test and fading acceleration test under color effect or color changed. Light fastness and fade grade can be known in short time. Those materials exposed at simulated sunlight to evaluated the material’s light fastness performance. To simulate and strengthen the test according to light energy, temperature, rain fall or condensation, humidity, .etc these main climate factors. Adopt simulated sunlight spectrum’s Xenon arc light to create destructive waves under different environment. It can be used for choosing new materials, improving existing materials, or assessment of durability change after material composed.
Xenon Accelerated Tester features:
1. Advanced design technology and concept
2. Excellent technology of producing and outstanding system of quality management,
3. Xenon lamp tester can be the most realistic simulated solar spectrum, including ultraviolet, visible and infrared.
4. A full range of spectrum, necessary for most textile sun and color fastness test.
Xenon Accelerated Tester technical parameters:
Model | XL - 1000 | |||||
Internal Dimension WxHxD (mm) | 900x900x900
| |||||
External Dimension WxHxD (mm) | 1500x2000x1400
| |||||
Tube Using Life (H) | 1500 | |||||
Tube Power | 1KW/6KW | |||||
Illumination Intensity | 340nm 0.35~0.6w/m2 | 420nm 0.8~3.5w/m2 | 300~400nm 48~60w/m2 | 300~800nm 520~800w/m2 | 300~1000nm 575~1000w/m2 | Full spectrum 1200±200w/m2 |
Lighting Filter Type | Inner filter | Borosilicate | Infrared adsorbing | Borosilicate | Infrared adsorbing | Quartz |
Outer filter | Borosilicate | Quartz | Soda lime | Infrared adsorbing | Quartz | |
Simulated Test Status | Test samples; Explore under sunlight | Test samples; Explore under sunlight(Below 300~ 1000nm) | Test samples: Explore under sunlight though glass window | Test samples: Explore under sunlight through glass window(Below 300~ 1000nm)
| Test samples: Explore under outer space | |
Cooling System | Water cooled or wind cooled | |||||
Temperature Control Range of the Test Cabinet | Black panel temperature : BPT 40~120°C(±3°C) | |||||
Black standard temperature :BST 38~120°C(±3°C) | ||||||
Humidity Control Range of the Test Cabinet | Humidity when lighting: 20%R.H.~75%R.H. (± 5%R.H.) | |||||
Humidity when dark: 60%R.H.~95%R.H. (± 5%R.H.) | ||||||
Rotating Speed of the Samples Holder(RPM) | 1~5 adjustable | |||||
Diameter of Sample Shelf(mm) | 500±50 | |||||
Sunlight Exposure Cycle | 0.01~999 hours 59mins | |||||
Raining Period/ Time | Raining Period:1~240mins,discontinuous-type, adjustable | |||||
Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa | ||||||
Spray Water Flow L/min) | 1~2.4 | |||||
Explore Area(cm2) | 7500 | |||||
Power | AC 380V 50/60HZ |
