Led electronic programmable thermal shocking tester
1. Led electronic programmable thermal shocking tester Features:
1. Wind route conversation to distribute temperature to the testing zone for cold and thermal shock
2.For high or low temperature shock, max. time is up to 999H, and max.circulation cycles are 9999 times.
3.The system can be used for automatic Circulation Shock or manual selective shock.
4.Adopt binary cooling system, with quick cooling effect.
5.RS-232 and RS-485 serial communication
6. 3-zone design: high temperature zone, low temperature zone, and the testing zone,
7. Touch-control operation interface for ease of use.
2. Led electronic programmable thermal shocking tester Application:
Programmable thermal shocking tester is applicable to metals, plastic, rubber, electronics amongst other materials. The test result can be used as a reference or basis for product improvement.
3. Led electronic programmable thermal shocking tester Technical parameters:
Model |
TS-42(A~C) |
TS-80(A~C) |
TS-150(A~C) |
TS-252(A~C) |
TS-450(A~C) |
||||
Interior size WxHxD (mm) |
400x350x350 |
500x400x400 |
600x500x500 |
700x600x600 |
800x750x750 |
||||
Exterior size WxHxD (mm) |
1400x1800x1400 |
1550x1950x1550 |
1600x2000x1700 |
1700x2100x1750 |
1800x2200x1900 |
||||
Temperature Range of Testing zone |
Type A:-40 °C~+150°C (200°C is Optional) |
Type B:-55°C ~+150°C (200°C is Optional) |
Type C:-65°C ~+150°C (200°C is Optional) |
||||||
|
High temperature Range of Testing zone: +60°C~+150°C(200°C is optional); Low Temp. Range of Testing Zone: -10°C~-40°C/-55°C/-65°C | |||||||||
Exposure Time of High / Low Temperature |
Exposure Time of High Temperature:+60°C~+150°C(200°C is Optional),30Mins |
||||||||
Exposure Time of Low Temperature:-10°C~Type B:-40°C/ Type B -55°C/ Type C -65°C,30Mins | |||||||||
Temperature of Heat-Storing Slot / Heating Time |
RT~200°C/About 45mins |
||||||||
Temperature of Cool-storing Slot / Cooling Time |
RT~-75°C/ About 100mins |
||||||||
Temperature Recovery Time / Conversion Time |
≤5min/≤5sec |
||||||||
Control Accuracy / Distribution Uniformity |
±0.5°C/±2°C |
||||||||
Interior and Exterior Material |
Interior material is SUS 304# stainless steel, exterior is stainless steel or see cold-rolled steel with paint coated |
||||||||
Insulation Material |
High temperature resistant, high density, formate chlorine, ethyl acetum foam insulation materials |
||||||||
Mechanics |
P.I.D+S.S.R+ Micro-computer balanced temperature control system |
||||||||
Cooling System |
Semi-hermetic double-stage compressor(water-cooled type) |
||||||||
Security Protection Devices |
Non-fuse breaker, high and low pressure protective switch of the compressor ,refrigerator high-pressure protective switch, failure warning system, electronic alarm |
||||||||
Accessories |
viewing window (Optional) |
||||||||
Compressor |
French Tecumseh , Germany Bitzer |
||||||||
Power |
AC220V or AC380V |
||||||||
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
4. Warranty: one year free warranty for whole set machine,lifelong time maintainance.
5. After-sale service: feedback within 2 hours after get the call.
6. Service: OEM service,Design service,Buyer lable service.
7.More pictures: Led electronic programmable thermal shocking tester:
