Mini Bench Top Chambers

Mini Bench Top Chambers thumbnail-1
Mini Bench Top Chambers photo-1
US$ 1,500 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Asli
Model Number:
DTH
Contact Supplier Request Quote Chat Now
Dongguan ASLi Test Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN /HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Asli
Model Number DTH
Power Electronic
Usage Universal Testing Machine

 Mini Bench Top ChamberS



       ASLI, as a leading mini bench top chamber supplier from China, has more than 25 year’s experience in mini bench top chamber manufacture. ASLI boost his own technical team in mini bench top chamber R&D,

and it also introduces the advance quality control method in mini bench top chamber production. Our mini bench top chamber series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.



Mini Bench Top Chamber Technical Parameters

Model

DTH-80A

DTH-80B

DTH-80C

Internal Dimensions WxHxD (mm)

400X500X400

External Dimensions WxHxD (mm)

1150X1150X1050

Temperature Range

(RT+10°C) ~+150°C

0~+150°C

-20 ~+150°C

Humidity Range

20%~98%R.H.

Indication Resolution/

Distribution Uniformity of

Temperature and Humidity

0.1°C; 0.1% R.H / ±2.0°C; ±3.0% R.H.

Control Accuracy

of Temperature and Humidity

±0.5°C; ±2.5% R.H.

Temperature Rising/Falling Velocity

Temperature rising approx.  0.1~3.0°C/min; temperature falling approx.

0.1~1.5°C/min;

Interior and Exterior Material

Interior material is SUS 304# stainless steel,exterior is stainless steel or

SEE cold-rolled steel with paint coated.

Insulation Material

Resistant to high temperature, high density, formate chlorine, ethyl

acetum foam insulation materials

Cooling System

Wind cooling

Protection Devices

Fuse-free switch, overloading protection switch  for compressor, high and

low voltage coolant protection switch, over-humidity and over-temperature

protection switch, fuses, fault warning system, water short storage

warning protection

Optional Accessories

Inner door with operation hole(Optional), Recorder(optional),Water Purifier

Compressor

 French Tecumseh Brand, Germany Bizer Brand

Power

AC 220V(±10%), 1& 3  Lines , 50/60HZ;

Weight (Kg)

75



 Mini Bench Top Chamber  Features :

1. Graceful appearance, circularly shaped body, surface treated with mist strips.

2. Rectangular double-paned viewing window for the observation of sample under test,with interior lights.

3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.

4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and

 automatically recyclable.

5.  French Tecumseh brand is used as compressor, with environment friendly refrigeration R23,R404A.

6.  LCD display screen is used for the control unit, capable of displaying set point and actual value at the same time

7. The control unit has the functions of multiples segment program editing, and of quick or ramp rates control of

temperature and humidity.

8. Casters are provided for ease of mobility, with strong positioning screws.



 Mini Bench Top  Chamber  Applications:

Mini bench top chamber is used to test various types of materials for their tolerances of heat, cold, dry, humidity,

and applied for quality inspection for all types of electronic products, electric appliance, and products from

communication, instrument, automobile, plastic, metal, food,  chemical, building materials, medical and aerospace

industries.



 Mini Bench Top Chamber Pictures: (for reference only)

Mini Bench Top Chambers







...
