Constant Temperature Humidity Climate Chamber
ASLI , as a leading climate chamber supplier from China, has more than 25 year’s experience in climate chamber manufacture. ASLI boost his own technical team in climate chamber R&D, and it also introduces the advance quality control method in climate chamber production. Our climate chamber series products are in compliance with the industrial standards, IE, ISO, ASMT, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, CSA and CEN.
Climate Chamber Application:
Programmable climate chamber is a special testing chamber used for various types of materials for their tolerance of heat,cold ,dry, humidity.It is applied for quality inspection for all types of electronic products, electric appliance and products of communication,instrument,automobile,plastic,metal,food ,chemical,building materials ,medical and aerospace industries.
Climate Chamber Features:
1. ASLI brand climate chamber has graceful appearance, circularly shaped body, surface treated with mist strips . Easy to operate, safe and reliable.
2. ASLI brand climate chamber has rectangular double-paned viewing window for viewing sample under test, with interior light
3. ASLI brand climate chamber has double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. ASLI brand climate chamber has water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. ASLI brand climate chamber has French Tecumseh is used as compressor, with environment friendly refrigeration R23 or R404A
6. ASLI brand climate chamber has LCD display screen, capable of displaying the measured value as well as the set value and time.
7. ASLI brand climate chamber has the control unit has the functions of multiples segment program editing, with quick or ramp rates control of temperature and humidity.
8. ASLI brand climate chamber has casters are provided for ease of mobility, with strong positioning screws
4. Technical Parameters :
Model |
F-TH-150(A~F) |
F-TH-225(A~F) |
F-TH-408(A~F) |
F-TH-800(A~F) |
F-TH-1000(A~F) |
|
Internal Dimension WxHxD( mm) |
500x600x500 |
600x750x500 |
600x850x800 |
1000x1000x800 |
1000x1000x1000 |
|
Internal Dimension WxHxD (mm) |
1100x1750x1600 |
1200x1800x1700 |
1250x1900x1900 |
1600x2050x2150 |
1700x2200x2300 |
|
Range of Fast Temperature Change |
Temperature Range: -70~+150ºC; Range of Fast Temperature Change: -45~+85ºC; Max. temperature rising/falling speed is 15ºC/min when the whole process with linear control . |
||||
Humidity Range(Optional) |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is a special optional condition,need Dehumidifier) |
||||
|
Analytic Accuracy/ Distribution Uniformity of Temperature and Humidity |
0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H. |
||||
|
Control Accuracy of Humidity |
±0.5ºC; ±2.5% R.H. |
||||
|
Temperature Rising/ FallingSpeed Rate |
The Temperature Rising/Falling Speed Rate with linear control : 3~15ºC/min, adjustable The Temperature Rising/Falling Speed Rate non-linear control : 3~30ºC/min, adjustable |
||||
Internal and External Material |
Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or SEE cold-rolled steel with paint coated. (temperature and humidity test chamber) |
||||
Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
||||
Cooling System |
Water cooling/single segment compressor |
||||
Protection Devices |
Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
||||
Optional Accessories |
Inner door with operation hole(Optional), Water Purifier, Dehumidifier |
||||
Compressor |
French Tecumseh Brand, Germany Bizer Brand |
||||
Power |
AC380V 3 ø 5 lines, 50/60HZ |
||||
Approx. Weight(Kg) |
250 |
350 |
450 |
600 |
700 |
5. Warranty: one year free warranty for whole set machine,lifelong time maintainance.
6. After-Sale Service: feedback within 2 hours after get the call.
7. More Pictures for Constant Temperature Humidity Climate Chamber
...
