temperature and humidity control oven
1. Application:
heated and humified incubators is also called environment testing machine, used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.
2. humidity control oven / Features:
• LCD Colour Touch Screen
• PLC microprocessor, PID Control of Temperature and Humidity
• Both Temperature and Humidity are Programmable (can have 100pattern, each pattern has 120 segment,can repeat pattern, segment or part of segment)
• With Digital Humidity Probe
• With RS232 output to computer
• Window Software
• All Stainless Steel (both interior and exterior)
• With Viewing Window
• With thermostats (prevent overheat)
• Cable Ports(50 or 100mm diameter)
• With Data Storage on Flash Card
• Protection (phase protection, overheat, over-current etc)
3.Technical Parameters:
Model |
TH-80(A~F) |
TH-150(A~F) |
TH-225(A~F) |
TH-408(A~F) |
TH-800(A~F) |
TH-1000(A~F) |
|
Internal Dimension WxHxD (mm) |
400x500 x400 |
500x600 x500 |
600x750 x500 |
600x850 x800 |
1000x1000 x800 |
1000x1000x1000 |
|
Enternal Dimension WxHxD (mm) |
950x1650 x950 |
1050x1750 x1050 |
1200x1900 x1150 |
1200x1950 x1350 |
1600x2000 x1450 |
1600x2100 x1450 |
Temperature Range |
Low Temperature(A:25ºC B:0ºC C:-20ºC D:-40ºC E:-60ºC F:-70ºC) High Temperature 150ºC |
|||||
Humidity Range |
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is a special optional condition, need Dehumidifier) |
|||||
|
Analytic Accuracy/ Distribution uniformity of temperature and humidity |
0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H. |
|||||
|
Control Accuracy of Temperature and Humidity |
±0.5ºC; ±2.5% R.H. |
|||||
|
Temperature Rising /Falling Speed Rate |
Temperature rising approx. 0.1~3.0ºC/min / temperature falling approx. 0.1~1.5ºC/min; ( The Falling Speed Rate Min.1.5ºC per minute is a special optional condition) |
|||||
|
Inner and Outer Material |
Material of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or SEE cold-rolled steel with paint coated. |
|||||
Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
|||||
Cooling System |
Wind cooling or water cooling/single segment compressor(-40ºC, double segment compressor -70ºC) |
|||||
Protection Devices |
Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
|||||
Optional Accessories |
Inner door with operation hole , Recorder, Water Purifier, Dehumidifier |
|||||
Compressor |
French Tecumseh Brand, Germany Bizer Brand |
|||||
Power |
AC220V 1ø3 lines, 50/60HZ , AC380V 3ø 5 lines , 50/60HZ |
|||||
|
Approx. Weight (Kg) |
150 |
180 |
250 |
320 |
400 |
450 |
4. Warranty: one year warranty for whole set machine
5. After-sale service: Feedback within 2 hours after get the call
6. more pictures for temperature and humidity control oven:
