Help CenterH.265 2.8-12mm Varifocal 4MP Real Time Economical ip Camera
Related Products
-
Cheap Cctv Security Cameras System Dahua Ipc Hdw1320S Ip67 ir Dome Poe Network ip Camera 3MP hd Camera With Sim CardNegotiableMOQ: 1 Set -
Gwsecu 2016 DAHUA 4MP HD WDR Network Vandal-proof IR Dome Camera IPC-HDBW5421E-ZUS$ 220 - 231MOQ: 1 Piece
-
Gwsecu 2016 DAHUA 4MP HD WDR Network Vandal-proof IR Mini Dome Camera IPC-HDBW4421E(-AS)US$ 126 - 133MOQ: 1 Piece
-
Gwsecu 2016 DAHUA 3MP Smart-series IR Network Dome Camera IR50m POE Ik10 IPC-HDBW8331E-ZUS$ 304 - 319MOQ: 1 Piece
-
Gwsecu 2016 DAHUA 4K Ultra HD Network IR Mini Dome Camera IPC-HDBW4800EUS$ 229 - 288MOQ: 1 Piece
|
|
|
| 2.0mp Bullet IP Camera | 2.0mp Dome IP Camera | 2.0 Bullet IP Camera |
|
|
|
| 1.3mp Dome Network Camera | H.265 2.0MP Network Camera | 3.0MP Network Camera |
>1/3" 4MP progressive scan CMOS
>High-performance Hisilicon DSP
>H.265&MJPEG video compression and JPEG image capture
>Max 20fps@4MP(2592×1520); 25/30fps 3.0MP/1080P /720P
>Dual encoding streams support
>WDR
>Day/Night(ICR)&3D DNR&AWB&AGC&BLC
>Support mobile phone monitoring and P2P function
>2.8~12mm /F1.4 Manual lens
>Built-in 1/1 alarm in/out
>Max IR Distance :30m
>True Day/Night ICR
>Micro SD memory, IK10, PoE
>Built-in Web server, NVR, CMS,APP
Model |
GWH-HD55AC84-P |
||
General | |||
Main Processor |
High-performance Hisilicon DSP |
||
Operating System |
embedded LINUX |
||
Resource |
Simultaneous remote monitoring local recording and remote control |
||
User Interface |
WEB CMS APP NVR |
||
Camera | |||
Image Sensor |
1/3" 4MP progressive scan CMOS |
||
Effective Pixels |
2592(H)×1520(V) |
||
Electronic Shutter |
1/5s to 1/50000s |
||
Mini. Illumination |
Color:0.3Lux/F1.2 ;B/W:0.05Lux/F1.2;0Lux/F1.2(IR on) |
||
Signal Noise Ratio |
>50dB |
||
Day/Night Mode |
Auto dual IR-Cut filter |
||
Gain Control |
Auto/Manual |
||
White Balance |
Auto/Manual |
||
WDR Dynamic Range |
100dB |
||
Lens |
2.8mm~12mm/F1.4Manual lens |
||
Max IR Distance |
30m |
||
Video | |||
Video Compression |
H.265/H.264/MJPEG Optional |
||
Coding standard |
H.265 Main Profile / H.264 baseline/H.264 Main Profile/H.264 High Profile Optional |
||
Video Bit Rate |
Main Stream:200Kbps~12Mbps Sub Stream:100Kbps~6Mbps |
||
Image Resolution |
4.0MP(2592×1520) / 3.0MP(2048×1536)/1080P(1920×1080)/ 720P(1280×720) / D1(704×576/704×480) |
||
Encoding Speed |
Main Stream: 4.0MP /20 fps max |
||
Extra Stream: 720P/25fps | |||
Video Format |
PAL/NTSC |
||
Audio | |||
Audio Compression |
G.711a/G.711u/RAW_PCM Optional |
||
Audio Bit Rate |
G.711a(8kbps)/G.711u(8kbps)/RAW_PCM(16kbps) |
||
Audio Input |
1-channel 3.5mm audio interface MIC IN/Line IN |
||
Audio Output |
1-channel 3.5mm audio interface (line level600Ω) |
||
Network | |||
Ethernet |
RJ-45 (10/100base-T) |
||
Network Protocol |
IPv4/IPv6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP |
||
ONVIF |
0NVIF Ver.2.4 |
||
Max User Access |
10 users |
||
Smart phone |
Iphone Ipad Android |
||
Remote Operation |
Monitor Playback System setting File download Log information Maintenance & Upgrade |
||
Browser |
IE(9,10,11)Chrome Firefox Safaribetc etc |
||
Auxiliary Interface | |||
Reset Input |
One Reset Button(Be effective after continues to hold down for 3 seconds) |
||
Memory Slot |
TF Card Max 64GB |
||
RS485 |
PTZ Control |
||
Alarm Input |
1-channel input Normally Open/Normally Close modes adjustable |
||
Alarm Output |
1-channel output 120VAC 1A/24VDC 1A |
||
Video Output |
1Vp-p Composite Output(75Ω/BNC) |
||
Environmental | |||
Power Supply |
DC12V |
||
Power Consumption |
<7W |
||
Operating Environment |
-40ºC ~ +60ºC Humidity less than95%(Non-condensing) |
||
IP Grade |
IP66 |
||
Dimensions(mm) |
154× 121.54mm |
||
Weight(kg) |
1.1kg |
||
PoE |
IEEE802.3af |
||
CMS&VSS Interface:
Web Interface:
Mobile Phone View:
