KDT-HA33XC72-P
1.3Mp CMOS HD Network Camera ip camera box camera
Features
> 1/3” 1.3 Megapixel Progressive Scan Aptina CMOS sensor
> Ti DaVinci Series DSP
> H.264&MJPEG video compression and JPEG image capture
> Support dual-stream encoding
> Max 25/30fps 1.3MP(1280×960) /720P(1280×720)
> Support ICR true Day/Night
> Support C/CS Auto lris lens
> Support Alarm I/O, RS485 interface
> Max 64 GB TF card for local storage
> Support BNC Video Output
> Support mobile phone monitoring and P2P function
1. Client Management Software
2. Web Interface
Contact Info.
Welcome to visit us!
1. Our office building:
2. Our Factory:
A. Raw Materials
Raw Materials sourced from trusted suppliers. Main raw materials like sensor, chipset and lens, we source from Sony, Ti and Aptina...
B. Assembling
As a professional HD IP Camera Manufacturer in China, we have a perfect management system in conformity with 6S methodology in manufacturing management to ensure that factory is really safe and clean. We also have all kinds of production and inspection equipment to maximize high-efficient production capacity while ensuring product quality.
C. Aging Products
24 hours aging testing precedure avoid defects, and make sure excellent performance of our products.
D. OEM&ODM
Customer LOGO can be printed on goods/color box/labels upon confirmed.
E. Quality Test
GWSECU adhering to the "quality first" principle. We provide superior products and services to our clients. Company invests abundant capital in advanced testing equipments to ensure products quality. Test including: Water-spray test, Constant temperature and moisture test, Transportation simulation test, Salt spray test, etc.
F. Packaging
Camera/NVR/DVR are packed with foam in individual color box, then color boxes are packaged in cartons, and all cartons having loading belt.
3. Exhibitions:
We participate various of exhibitions every year, you can find us at CPSE in China, ISC in America, IFSEC
in Britain, INTERSEC in Dubai, SST in Russia, SECUREX in South Africa, …
About us
Shenzhen Guowei Security Co., ltd is a national high - tech enterprise that integrates the design, development, production and sales of network video surveillance products.
Gwsecu has a professional and experienced R&D team that well knows core technologies, pursuing products with reliability, complement and compatibility. To guarantee stable performance, Gwsecu has strict control on design, raw material and processing of its products. Its IP Camera and NVR series have passed international ONVIF standards, perfectly compatible with China’s mainstream storage device suppliers (Dahua, Hikvision etc.) and overseas platform (MILESTONE, DIGIFORT etc.).
Established in 2001, the national high - tech enterprise and a membership of ONVIF organization—Gwsecu, has passed ISO9001 quality management system authentication and all the products have been successfully certificated by CE, FCC, ROHS.
FAQ
1. Payment
What are the terms of payments you offer?
We accept payment via T/T, Paypal, Westunion etc
2. Shipment
How long will it takes to deliver goods?
We will deliver your goods within 7-10 working days after an order confirmed
What kind of packaging you offer?
We will pack the goods well with exporting packages and bubble wrap to make sure all goods in a good condition during storage and delivery.
What kind of transportation methods you offer?
A. We usually use express delivery like DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies.
B. We also can deliver your goods by air and sea as your request.
3. Our Services
Warranty: We cover 2 Year warranty for all our products since shipment day.
For all your inquiries about our products, we will reply you in detail within 24 hours.
Technical Specifications
Model |
KDT-HA33XC72-P |
|
General | ||
Main Processor |
Ti DaVinci Series DSP |
|
Operating System |
Embedded LINUX |
|
Capacity |
Simultaneous remote monitoring, local recording and remote control |
|
User Interface |
WEB, CMS, NVR |
|
Camera | ||
Image Sensor |
1/3" 1.3Megapixel Progressive Scan Aptina CMOS Sensor |
|
Effective Pixels |
1280(H)×960(V) |
|
Electronic Shutter |
1/5s to 1/50,000s |
|
Mini. Illumination |
Color:0.1Lux/F1.2 ;B/W:0.005Lux/F1.2 |
|
Signal Noise Ratio |
>50dB |
|
Day/Night Mode |
Auto, dual IR-Cut filter |
|
Gain Control |
Auto/Manual |
|
White Balance |
Auto/Manual |
|
WDR Dynamic Range |
DWDR |
|
Lens Mount |
C/CS |
|
Auto lris |
Support |
|
Video | ||
Video Compression |
H.264/MJPEG Optional |
|
H.264 Encode Type |
H.264 Baseline/H.264 Main Profile/H.264 High Profile Optional |
|
Video Bit Rate |
Main Stream:200Kbps~8Mbps Sub Stream:100Kbps~6Mbps |
|
Image Resolution |
1.3MP(1280×960) / 720P(1280×720) / D1(704×576/704×480) |
|
Encoding Speed |
Main Stream: 1.3MP/720P/D1(1~25fps/30fps) |
|
Extra Stream: D1/CIF (1~25fps/30fps) | ||
Video Format |
PAL/NTSC |
|
Analog Video Output |
1 channel BNC (1.0Vp-p, 75Ω) |
|
Audio | ||
Audio Compression |
G.711a/G711u Optional |
|
Audio Bit Rate |
G.711a(8kbps)/G.711u(8kbps) |
|
Audio Input |
1-channel 3.5mm audio interface MIC IN/Line IN |
|
Audio Output |
1-channel 3.5mm audio interface (line level ,600Ω) |
|
Network | ||
Ethernet |
RJ-45 (10/100Base-T) |
|
Network Protocol |
Ipv4/Ipv6,RTSP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP |
|
Common Features |
One button Reset, Prevent Flicker, Dual-stream, Heartbeat, Password Protect, Video cover, Motion Alarm |
|
ONVIF |
ONVIF Ver.2.4 |
|
Max User Access |
10 users |
|
Smart phone |
Iphone , Ipad ,Android, |
|
Remote Operation |
Monitor, System setting, Log information, Maintenance & Upgrade. |
|
Auxiliary Interface | ||
Reset Input |
One Reset Button(Hold on 3 seconds at least) |
|
SD Card |
Max 64GB, local storage |
|
RS485 |
PTZ control |
|
Alarm Input |
1-channel input ,Normally Open /Normally Close modes adjustable |
|
Alarm Output |
1-channel output ,120VAC 1A/24VDC 1A |
|
Video Output |
1Vp-p Composite Output(75Ω/BNC) |
|
Environmental | ||
Power Supply |
DC12V |
|
Power Consumption |
<3W |
|
Working Environment |
-40ºC ~ +60ºC, Humidity less than95%(Non-condensing) |
|
PoE |
IEEE802.3af |
|
Dimensions(mm) |
150.2mm×77.7mm×55.8mm |
|
Weight(kg) |
0.51KG |
|
